A Collaborative Design and Analysis Environment for Flexible Fixture

Abstract:

Designing a flexible fixture is much more complicated. In this paper a collaborative environment was introduced for flexible fixture design. The tasks involved in fixture design are analyzed and decomposed into five subtasks, which are assigned to workgroups by a project manager. The workgroups can be distributed in different departments or in different locations geographically. The framework of collaborate design environment is constructed. Each workgroup is responsible to a certain job. However, the information needed for flexible fixture design is shared among these workgroups. The information exchanging and management in the environment are expressed with a block diagram. Finally, an example of flexible fixture for manufacturing a thin-walled workpiece is employed to illustrate the efficiency of the collaborative environment.

• Periodical: Key Engineering Materials (Volumes 407-408)
• Pages: 225-229
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.407-408.225
• Online since: February 2009
• Authors: Wei Fang Chen, Jian Bin Xue, Pei Huang Lou
• Keywords: Collaborative Design, Digital Fixture Design, Flexible Fixture, Thin-Walled Workpiece

References

[1] Z.M. Bi and W.J. Zhang: Production Research, Vol. 39 (2001), No. 13, pp.2867-2894.

[2] F. Mervyn, A.S. Kumar and et al: Computer Aided Design, Vol. 35(2003), No. 10, pp.945-957.

[3] X. William Xu and T. Liu: Robotics and Computer Integrated Manufacturing, Vol. 19(2003), No. 4, pp.315-328.

[4] Y.M. Rong: Advanced Computer Aided Fixture Design (Elsevier Academic Press, UK, 2005).

[5] R. Hunter, A. Vizan and J. Perez: Materials Processing Technology, Vol. 164-165(2005), pp.1510-1518.

[6] D.B. Tang: Computer in Industry, Vol. 54(2004), No. 3, pp.253-271.

[7] W. Li, P.G. Li and Y. Rong: Materials Processing Technology, Vol. 128(2002), No. 1-3 , pp.7-18.

[8] Kaya Necmettin: Computers in Industry, Vol. 57 (2006), No. 2, pp.112-120.

[9] H. Song and Y. Rong: Robotics and Computer Integrated Manufacturing, Vol. 21(2005), No. 4-5, pp.368-378.

[10] Y. Wang, X. Chen and Q. Liu: Machine Tools and Manufacture, Vol. 46(2006), No. 12-13, pp.1291-1300.

[11] S.P. Siebenaler and S.N. Melkote: Machine Tools and Manufacture, Vol. 46(2006), No. 1, pp.51-58.

[12] Y.C. Kao and G.C. I Lin: Robotics and Computer Integrated Manufacturing, Vol. 14(1998), No. 1, pp.55-68.

[13] Y.W. Bai, Z.N. Chen and H.Z. Bin: Robotics and Computer Integrated Manufacturing, Vol. 21 (2005), No. 1, pp.55-65.

[14] K.Y. Kim, D.G. Manley and H.J. Yang: Computer Aided Design, Vol. 38(2006), No. 12, pp.1233-1250.
