Simulation Research on the Swirling Airflow Compounded with Magnetic-Field Finishing

Abstract:

A new finishing technology of the swirling airflow compounded with magnetic-field is advanced. Machining prediction is carried through by simulating magnetic field and flow field. Abrasive velocity and grinding pressure according to injection pressure and abrasive diameter are shown. Unthreaded hole is experimented on the condition of adding magnetic field or not and the decrease of surface roughness on eight sampling points along axis is obtained. Research indicates that the swirling airflow compounded with magnetic-field finishing is feasible from the simulation and Adding magnetic field may avoid the ununiformity of finishing as well as increase finishing effect.

• Periodical: Key Engineering Materials (Volumes 407-408)
• Pages: 658-661
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.407-408.658
• Online since: February 2009
• Authors: Xiu Hong Li, Sheng Qiang Yang, Shi Chun Yang, Wen Hui Li
• Keywords: Finishing, Magnetic Field, Simulation, Swirling Airflow, Two-Phase Flow

References

[1] M.C. Shaw: Principles of Abrasive Processing, (Oxford University Press, Oxford 1996).

[2] Massimiliano Barletta, Stefano Guarino: International Journal of Machining Tool & Manufacture, vol. 47 (2007), pp.483-451.

[3] Sunil Jha V.K. Jain: International Journal of Machine Tools & Manufacture, vol. 44 (2004), pp.1019-1025.

[4] S.C. Yang, S.Q. Yang, T.M. Wang: Processing and abrasives ( 2002), pp.13-16.

[5] S.C. Yang, M.Z. Wang: Surface Quality and Finishing Technology, (Machinery Industry Press, Beijing 2000).

[6] M.B. Tian: Magnetic Materials (Tsinghua University Press, Beijing 2000). Decrease of surface roughness Ra (µm).
