Thermal Modeling and Analysis for Grinding Operation

Abstract:

This paper focuses on the effects of heat source profiles during thermal analysis of grinding. Three different models of heat source, namely triangular model, parabolic model and elliptic model, have been suggested and their numeric formulas are provided. These models take into account of the variation of heat flux along the contact zone, so as to improve the accuracy of numeric results. Finite Element Analysis (FEA) is utilized to investigate the temperature distributions under different thermal models and the effects of two profile parameters (η and ξ). The result is a) peak temperature decreases as η increases and the location of peak value moves backwards simultaneously; b) peak temperature decreases as ξ increases and the location of peak value moves forwards simultaneously.

You might also be interested in these eBooks

Functional Manufacturing Technologies and Ceeusro I

View Preview

Info:

Periodical:

Key Engineering Materials (Volumes 426-427)

Pages:

624-628

DOI:

https://doi.org/10.4028/www.scientific.net/KEM.426-427.624

Citation:

Cite this paper

Online since:

January 2010

Authors:

Yan Ding Qin, Yan Ling Tian, Da Wei Zhang

Keywords:

Grinding, Heat Source Profile, Temperature Distribution, Thermal Analysis

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] J. C. Jaeger: Proceedings of the Royal Society of New South Wales Vol. 76 (1942), pp.203-224.

Google Scholar

[2] E. Brinksmeier, J. C. Aurich, E. Govekar, et al.: Annals of the CIRP Vol. 55 (2006), pp.667-696.

Google Scholar

[3] D. A. Doman, A. Warkentin, R. Bauer: International Journal of Machine Tools and Manufacture, Vol. 49 (2009) pp.109-116.

DOI: 10.1016/j.ijmachtools.2008.10.002

Google Scholar

[4] J. Bei: Journal of Shanghai Jiaotong University Vol. 3 (1964), pp.16-18.

Google Scholar

[5] W. B. Rowe, S. C. E. Black, B. Mills, et al.: Annals of the CIRP Vol. 44 (1995), pp.329-332.

Google Scholar

[6] T. Jin, D. J. Stephenson: International Journal of Machine Tools and Manufacture, Vol. 46 (2006), pp.1862-1868.

Google Scholar

[7] M. Mahdi, L. Zhang: Computers & Structures Vol. 58 (1995), pp.313-320.

Google Scholar

[8] M. Mahdi, L. Zhang: Computational Mechanics Vol. 26 (2000), pp.148-156.

Google Scholar

[9] Z. B. Hou, R. Komanduri: International journal of Heat and Mass Transfer Vol. 43 (2000), pp.1679-1698.

Google Scholar

[10] Y. Tian, B. Shirinzadeh, D. Zhang, et al.: Precision Engineering (2008) doi: 10. 1016/j. precisioneng. 2008. 12. 002.

Google Scholar

[11] C. Guo, S. Malkin: Journal of Manufacturing Processes Vol. 2 (2000), pp.151-157.

Google Scholar
