Simulation and Fuzzy Control Study on the CVT Metal V Belt Axial Misalignment of Car

Abstract:

Based on the analysis of the belt misalignment of the metal V belt CVT, the reason of the belt misalignment has been discussed. In order to control the misalignment, an electro-hydraulic control system has been designed. After deeply analyzing the structure and principle of the electro-hydraulic control system, the mathematical model of the electro-hydraulic control system has been established. Being varieties of the working situation of car and the non-linearity of the electro-hydraulic control system, A Fuzzy PID algorithm has been designed. Then the simulation of the belt misalignment has been conducted, and the simulation results show that the electro-hydraulic control system and the fuzzy controller could not only control ratio, which had a higher accuracy of the stable state and a stronger robust of the driving condition, but also eliminated the belt misalignment, improved the dynamic performance of the metal V belt CVT.

• Periodical: Key Engineering Materials (Volumes 426-427)
• Pages: 97-101
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.426-427.97
• Online since: January 2010
• Authors: Fa Ye Zang
• Keywords: CVT, Fuzzy Control, Metal V Belt, Misalignment, Simulation

References

[1] H. Emery: SAE Paper Vol. 881734(1988), pp.1311-1321.

[2] G. Nitescu: Antrieb Stechnik Vol. 23(1984)No. 7, pp.46-49.

[3] A. Hiroki: JSAE Review 9532209 (1995), pp.171-174.

[4] D.C. Sun: Transaction of the ASME Vol. 110(1996), pp.472-481.

[5] B.Y. Zhang, Y.S. Zhou and Y.K. Zhang: Automotive Engineering Vol. 23 (2001) No. 5, pp.315-318.
