Effects of Relative Position of Balls and Tool on the Formation of Axial Micro Grooves Inside Circular Micro Heat Pipe during Spinning

Abstract:

Based on the principle of spinning process of micro grooves inside the circular micro heat pipe, the effects of relative position of balls and tool on the formation of micro grooves were investigated in this work. Experimental results showed that the relative position of balls and tool and ball equivalent diameter generally determined the pattern of grooves, including groove width and depth. Micro grooves could be produced when suitable value of D was chosen and the rake face of tool was near to the center of balls. In the experiment, the largest aspect ratio of micro grooves were achieved with the conditions of D= 5.56mm, d=-3.293mm and v=5.08mm/s. And the structural parameters were w=135μm, h=154μm and k=1.141.

You might also be interested in these eBooks

Machining and Advanced Manufacturing Technology X

View Preview

Info:

Periodical:

Key Engineering Materials (Volumes 431-432)

Pages:

70-73

DOI:

https://doi.org/10.4028/www.scientific.net/KEM.431-432.70

Citation:

Cite this paper

Online since:

March 2010

Authors:

Min Qiang Pan, De Huai Zeng, Xiao Qing Liu, Yong Tang

Keywords:

Aspect Ratio, Axial Micro Groove, Heat Pipe, Spinning

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] A.K. Mallik, G.P. Peterson and M.H. Weichold: J. Microelectromechanical Systems, Vol. 4 (1995), pp.119-131.

Google Scholar

[2] S. Kang, S. Tsai and H. Chen: Appli. Therm. Eng. Vol. 22 (2002), pp.1559-1568.

Google Scholar

[3] C. Gillot, Y. Avenas, N. Cezac, G. Poupon, C. Schaeffer and E. Fournier: IEEE transactions on Components and Packaging Technologies, Vol. 2 (2003), pp.332-339.

DOI: 10.1109/tcapt.2003.815092

Google Scholar

[4] M. Lee, M. Wong and Y. Zohar: J. Microelectromechanical Systems, Vol. 2 (2003), pp.138-146.

Google Scholar

[5] Y. Tang, Y. Chi, J. Chen, X. Deng, L. Liu, X. Liu and Z. Wan: Int. J. Mach. Tool Manufact, Vol. 47(7-8) (2007), pp.1059-1068.

Google Scholar
