Probabilistic Fracture Mechanics Analysis of Multiple Cracks in Cylindrical Pressure Vessel

Abstract:

In this work, a probabilistic fracture mechanics analysis of multiple cracks in a cylindrical pressure vessel was conducted. The analysis was performed to predict service life of a pressure vessel with a certain level of reliability if the vessel has a multiple internal surface cracks that interact each other. The stress intensity factor of multiple cracks configuration was determined from the stress intensity factor of a single surface crack in a plate subjected to uni-axial load and the interaction factor between the cracks. In this work, the Swift’s crack link-up criterion was employed. These parameters together with several other stochastic parameters, i.e. initial crack size, Paris’s crack propagation constants and fracture toughness, were then used to calculate the probability of failure with a certain level of reliability. The failure probability was simulated using guided direct simulation, for cycle-by-cycle crack propagation, to find the expected service life and the mode of failure (leak or break). A case study of a high-pressure vessel having different initial crack sizes have been simulated and the service life with 99,99% reliability were determined.

• Periodical: Key Engineering Materials (Volumes 462-463)
• Pages: 1314-1318
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.462-463.1314
• Online since: January 2011
• Authors: Tatacipta Dirgantara, Tuppi Summa Wicaksono, Thahir Ahmad, Indra Sadikin, Djoko Suharto, Ichsan Setya Putra
• Keywords: Fracture Mechanic, High-Pressure Vessel, Multiple Crack, Probabilistic Analysis, Stress Intensity Factor (SIF)

References

[1] I. Sadikin, and D. Suharto: Key Engineering Materials Vol. 306-308 (2006), p.691.

[2] I. Sadikin, I., Suharto, D., Meliana, B., Supelli, K., Arya: Advanced Materials Research, Vol. 33-37 (2008), p.79.

DOI: 10.4028/www.scientific.net/amr.33-37.79

[3] T. Swift. In Proceedings 5th International Conference on Structural Airworthiness of New and Aging Aircraft, (1993) p.133.

[4] W.O. Soboyejo, K. Kishimoto, R.A. Smith & J.F. Knott: Fatigue Fracture Engineering Mat. Struc., Vol. 12 (1989), p.167.

[5] J.C. Newman and I.S. Raju: Stress Intensity Factors for Internal Surface Cracks In Cylindrical Pressure vessels. (NASA Langley Research Center, Virginia 1979).

[6] J.C. Newman and I.S. Raju: Stress Intensity Factor Equations for Cracks in Three-Dimensional Finite Bodies. (NASA Langley Resesarch Center. Hampton, Virginia 1981).

[7] Raju Sethuraman, G. Siva Sankara Reddy, I. Thanga Ilango. Int. J. of Press. Vessels and Piping Vol. 80 (2003) p.843.

DOI: 10.1016/j.ijpvp.2003.10.003
