Design of Large Deployable Networks Constructed by Myard Linkages

Abstract:

This paper investigates the possibilities of building large deployable mechanical network based on Myard linkage, a 5R overconstrained linkage. The motion configurations of a Myard linkage is first briefly introduced, and the results show that the linkage is a good candidate for forming large spatial deployable structures which can be deployed to a planar configuration and folded to a compact bundle. Three kinds of assembly ways of Myard linkages are introduced. Afterwards, two types of large spatial deployable networks based on Myard linkages with different twist angles are developed.

• Periodical: Key Engineering Materials (Volume 486)
• Pages: 291-296
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.486.291
• Online since: July 2011
• Authors: Xiao Zhi Qi, Zong Quan Deng, Bing Ying Ma, Bing Li, Rong Qiang Liu
• Keywords: Large Deployable Networks, Myard Linkage, Tilings

References

[1] Gökhan Kiper, Eres Söylemez. 2009 4th International Conference on Recent Advances in Space Technologies. (2009) p.131

[2] L. Puig, A. Barton, N. Rando. Acta Astronautica. Vol.67 (2010) p.12

[3] Chen Y and You Z. Proceedings of the Royal Society A (Mathematical, Physical and Engineering Sciences). Vol.461 (2005) p.1229

[4] Chen Y and You Z. Proceedings of the Royal Society A (Mathematical, Physical and Engineering Sciences). Vol.464 (2008) p.1275

[5] S.Y. Liu, Y. Chen. Mechanism and Machine Theory. Vol.44(2009) p.(1950)

[6] F.E. Myard, Contribution à la géométrie des systèmes articulés, Societe mathématiques de France 59 (1931) 183–210

DOI: 10.24033/bsmf.1179

[7] B. Grünbaum, G.C. Shephard, Tilings and Patterns, W.H. Freeman and Compa986
