Problems of Analytical Determination of Journal Bearing Bush Fatigue Strength Estimates

Abstract:

Problems connected with determination of stress distribution in sliding layer of thin-walled bearing bushes, investigated in bearing fatigue test rigs, have been presented. Using an example of plain bearings tested in the fatigue machine SMOK (built at the Gdańsk University of Technology) problems with obtaining a convergence of iterative procedure for determining the fatigue strength estimators of bearing alloy surface layer are analyzed. Calculations consisting in successive iterations of pressure distribution in oil film and corresponding elastic deformation of the bearing bush and housing were based on finite-element method and utilized ANSYS program. The objective of calculation was the estimation of values of radial, tangential, axial and reduced stresses in surface layer of the bearing bush corresponding to experimentally determined load magnitudes leading to fatigue cracks initiation. The convergence of analytical procedure has been achieved by the use of a relaxation method.

• Periodical: Key Engineering Materials (Volume 490)
• Pages: 247-256
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.490.247
• Online since: September 2011
• Authors: Rafał Gawarkiewicz, Jan Sikora, Boguslaw Siwek
• Keywords: Analytical Method, Fatigue Strength Estimates, Journal Bearing, Slide Bearing Research

References

[1] O.R. Lang, Surface Fatigue of Plain Bearings, Wear 1977, Vol. 43, 25-33.

[2] F.A. Martin, D.R. Garner, D.R. Adams, Hydrodynamic Aspects of Fatigue in Plain Journal Bearings, ASME, Journal of Lub. Technology 1981, Vol. 103, 150-161.

DOI: 10.1115/1.3251604

[3] ISO 7905-1:1995, Plain bearings - Bearing fatigue - Part 1: Plain bearings in test rigs and in applications under conditions of hydrodynamic lubrication.

DOI: 10.3403/30412531

[4] J. Sikora, Methodology of investigation of plan journal bearing fatigue strength, Gdańsk University of Technology, Gdańsk 1996, Mechanika Nr 534, (in Polish).

[5] J. Sikora, Research Problems of Fatigue Strength of Bearing Slide Layers, Gdańsk University of Technology, Gdańsk 2009 (in Polish).

[6] www.ansys.com

[7] J. Kiciński, Theory and investigation of hydrodynamic plan journal bearings, Rotating Machinery, t. 15, PAN, Wrocław-Warszawa-Kraków 1994 (in Polish).
