Research Progress on Digital Design and Manufacturing for Solid Carbide End Mill

Abstract:

This paper summarizes the research progress of integral end milling cutter and series of common theories and methods: the construction in the reasoning machine of end milling cutter structure parameters, obtained structure parameter according to the type and the main design parameters of end milling cutter; General the mathematical model and the geometric modeling method of end milling cutter ,based on structure parameters that get from reasoning machine, get 3D parametric model which include all structure information and manufacturing characteristic of end milling cutter; the design technology of end milling cutter Based on manufacturing simulation, check the tool-position trajectory quickly by 2D curved shapes from 2D section Boolean operation, then validate the process rationality and manufacturability of end milling cutter via combine the 2D section simulation technology and the 3D manufacturing simulation. Present some research results finally, the detailed studies details will report in the subsequent articles.

• Periodical: Key Engineering Materials (Volume 499)
• Pages: 289-294
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.499.289
• Online since: January 2012
• Authors: Guo Fu Ding, X.F. Cheng, R. Li, J.J. Liu, R. Mi
• Keywords: Digital Design, Inference Machine, Integral End Milling Cutter, Machining Simulation

References

[1] Z.G. Hu, H.Q. Zhou and M. Chen: The Magazine on Equipment Machinery Vol. (3) (2003), p.7

[2] Z.Q. Liu and X. Ai: Tool Engineering Vol. 35(3) (2001), pp.3-8.

[3] M.H. Jone and C.T. Ying: Adv Manuf Technol Vol.29(2009), P.912

[4] S.K. Kang, K.F. Ehmann and C. Lin: Tools Manufac Vol.36(1), P.141

[5] C.T. Wu and C K. Chen: Journal of Materials Processing Technology (2001) P.114

[6] Y.Y. He, Y.H. Zhou and J. Zhou: Journal of Huazhong University of Science and Technology Vol.26(4) P.53

[7] F.J. Chen: Simulation Technology Vol.(2) (2008), P.43

[8] C.P. Wang, Y.H. Zhou and Y.G. Zhou: China Mechanical Engineering Vol.10(2)(1999), p.123

[9] F.Xiong, H.Z. Bin and J.X. Jin: China Mechanical Engineering Vol.12(11)(2001), pp.1253-1255.
