Simulation of Micro-Gear Manufactured by Differential Injection Molding Based on Moldex 3D

Abstract:

In this article, the structure of the differential pump is introduced, which is the core part of the differential injection system. The micro-gear with a shaft collar is simulated as it is an important micro-part and has great potential application in mechanical transmission. The Moldex 3D simulation software is used to investigate effects of processing parameters on the micro-gear such as melt temperature, mold temperature, injection time and packing time etc. By comparing the micro-gear's warpage under different processing parameters, it can be concluded that melt temperature has a greater impact on the molding quality than mold temperature. In addition, the effects of injection time and packing time on the micro-gear's molding quality are also investigated.

• Periodical: Key Engineering Materials (Volume 501)
• Pages: 269-273
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.501.269
• Online since: January 2012
• Authors: Peng Cheng Xie, Li Lei Miao, Pan Pan Zhang, Wei Min Yang
• Keywords: Differential Injection System, Differential Pump, Moldex 3D, Warpage

References

[1] PENG Yun-feng, LI Gui-xian, Basic Research of M icro-gears, Machine Design and Research. 21 (2005) 41-43.

[2] Liu Ye, QU Xuanhui, Yin Haiqing, Effect of the process parameters on alum ina ceramic micro-gear injection molding in numerical simulation, Powder Metallurgy Technology. 28 (2010) 381-386.

[3] Wu Shaolong, Lou Baiyang, Injection molding micro-gear orthogonal numerical simulation and optimization, Engineering Plastics Application. 39 (2011) 43-45.

[4] Ming-Shyan Huang, Chen-Jung Li, Jyh-Cheng Yu, Yung-Ming Huang, Li-Chung Hsieh, Robust parameter design of micro-injection molded gears using a LIGA-like fabricated mold insert, J. Mater. Process. Technol. 209 (2009) 5690-5701.

DOI: 10.1016/j.jmatprotec.2009.05.032

[5] DAI Ya-chun, WANG Yun , ZHOU Jian-zhong et al., Injection Molding Micro-gear Orthogonal Optimization and Numerical Simulation, Material technology. 7 (2010) 46-48.

[6] SUN Yazhou, LIANG Yingchun, CHENG Kai, Miniaturized Manufacturing Machine and Micro Manufacturing System, China Mechanical Engineering. 13 (2002) 592-596.

[7] ZHAO J, MAYES R H, CHEN G et al., Polymer micro mould design and micro molding process, Plast Rubber Compos. 32 (2003) 240-247.

[8] SHEN Y K, SHIE YJ, WU W Y, Extension method and numerical simulation of micro-injection molding, Int. Commun. Heat Mass Transfer. 31 (2004) 795-804.

DOI: 10.1016/s0735-1933(04)00066-1

[9] DAI Ya-chun, WANG Yun, ZHOU Jian-zhong et al., Injection Molding Micro-gear Orthogonal Optimization and Numerical Simulation, Material technology. 7 ( 2010) 46-48.
