Study on the Submarine Pipeline with Flexible Spoilers

Abstract:

Two new methods which use flexible spoilers to protect submarine pipelines are proposed. One is put flexible spoiler on the top of the pipe to make pipe self-buried. The other is put flexible spoiler under the pipe to stop the erosion under the pipe. Through physical experiments, the pressure distribution and scour hole around the submarine pipeline with flexible deflectors were studied. Experiment results point out that top flexible spoiler can increase the resistance of the pipe, increase the scour hole depth, accordingly make the pipeline be self-buried. The flexible spoiler under the pipe can reduce the pressure difference between both sides of the pipeline, diminish the scour hole depth obviously and even to stop scour.

• Periodical: Key Engineering Materials (Volume 501)
• Pages: 431-435
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.501.431
• Online since: January 2012
• Authors: Yan Han
• Keywords: Experimental Study, Flexible Spoiler, Pressure Distribution, Scour Hole, Submarine Pipeline

References

[1] Gokce K.T. Gunbak A.R, Self burial and stimulated self burial of pipelines by waves, Proc., 1st Int. Conf. on Offshore and Polar Engrg. (1991)

[2] Hulsbergen, C.H., Stimulated self-burial of submarine pipelines, OTC 4467, (1984)

[3] Y. M. Chiew, Effect of spoilers on wave-induced scour at submarine pipelines, Waterway, Port, Coastal and Ocean Engineering, ASCE, 119(4), (1993)

DOI: 10.1061/(asce)0733-950x(1993)119:4(417)

[4] Chiew, Y.M., Effect of spoilers on scour at submarine pipelines. J. Hydraul. Eng, ASCE 118 (9) (1992)

DOI: 10.1061/(asce)0733-9429(1992)118:9(1311)

[5] L. Cheng, L.W. Chew, Modelling of flow around a near-bed pipeline with a spoiler, Ocean Engineering, 30 (2003)

DOI: 10.1016/s0029-8018(02)00148-8

[6] B.M. Sumer, C.Truelsen,T. Sichmann, J. Fredsøe, Onset of scour below pipelines and self-burial, Coastal Engineering, 42, (2001)

DOI: 10.1016/s0378-3839(00)00066-1

[7] Yang Bing, Gao Fuping and Wu Yingxiang, Experimental study on local scour of sandy seabed under submarine pipeline in unidirectional currents, Engineering mechanics, 25(3)(2008)

[8] Jensen B.L., Flow around and forces on a pipeline near a scoured bed, Chung J. Proceedings of the 7th Internation al Sym posium on Ofshore M echanics andAr ctic Engineering, Houston Texas. (1988)

[9] Gao F P, Yang B, Wu Y X, Yan S M, Steady currents induced seabed scour around a vibrating pipeline, Applied Ocean Research, 28(5), (2006)

DOI: 10.1016/j.apor.2007.01.004
