2D Meshless Solution of Elastoplastic with Damage Problem

Abstract:

The Finite Element Method (FEM) is today the most widely used in numerical simulation of forming processes, due essentially to the continuous improvement of the FEM over the years and the simplicity of its implementation. However, this method has some limitations such as the distortion of elements under large inelastic deformation and the influence of the mesh on the results in several applications. The simulation of metal forming process with large plastic strain is a classical example where the successive remeshing is often the proposed solution in this case. But the remeshing raises the problems of precision and computing time. In this context and in order to avoid the remeshing process, a Meshless method is experimented in the solving of an elastoplastic problem coupled to the isotropic ductile damage. An Element Free Galerkin (EFG) method based on Moving Least Square (MLS) concept is considered in this proposal. A two-dimensional Mechanical problem was studied and solved by a Dynamic-Explicit resolution scheme where the material behaviour is based on an isotropic hardening fully coupled to ductile damage model. In a first step a parametric study is conducted in order to find the most influent parameters on the accuracy of the results. The effect of the number of nodes, of support nodes, of quadrature points, the effect of the time-step and the support domain size are analysed and optimal values are found. In a second step, the meshless results are compared with those of the finite element method and some concluding remarks relative to the accuracy and the computing time are given.

• Periodical: Key Engineering Materials (Volumes 504-506)
• Pages: 413-418
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.504-506.413
• Online since: February 2012
• Authors: Zohra Sendi, Carl Labergère, Khemais Saanouni, Hedi Belhadj Salah
• Keywords: Damage, Dynamic Explicit, Elasto-Plasticity, Isotropic Hardening, Meshless

References

[1] Liu, G.R.; Gu, Y.T, An introduction to meshfree methods and their programming. Dordrecht; Springer; 2005.

[2] Nayroles, B.; Touzot, G.; Villon, P.: Generalizing the Finite Element Method: Diffuse Approximation and Diffuse Elements. Comput. Mech.,10, 307 - 318, 1992.

DOI: 10.1007/bf00364252

[3] Belytschko, T.; Krongauz, Y.; Organ, D.; Fleming, M.; Krysl, P.: Meshless Methods: An Overview and Recent Developments. Comp. Methods Appl. Mech. Engrg., 139, 3 -47, (1996)

DOI: 10.1016/s0045-7825(96)01078-x

[4] Atluri, S.N.; Shen, S.: The Meshless Local Petrov-Galerkin (MLPG) Method. Tech Science Press, Stuttgart, 2002.

[5] Badreddine H., Saanouni K., Dogui A. On non-associative anisotropic finite plasticity fully coupled with isotropic ductile damage for metal forming, International Journal of Plasticity, Volume 26, Issue 11, November 2010, Pages 1541-1575

DOI: 10.1016/j.ijplas.2010.01.008

[6] Saanouni K. , Belamri N., Autesserre P, Finite element simulation of 3D sheet metal guillotining using advanced fully coupled elastoplastic-damage constitutive equations, Finite Elements in Analysis and Design, Volume 46, Issue 7, July 2010, Pages 535-550

DOI: 10.1016/j.finel.2010.02.002
