The Model for Coupled Simulation of Thin Profile Extrusion

Abstract:

The paper presents the latest development of the numerical model for extrusion of industrial profiles having complex shapes. The model provides the material flow analysis coupled with mechanical and thermal problems in the tooling set. The simulation predicts possible shape deterioration due to uneven material flow through the bearing zone and helps to equalise it by means of optimisation of the bearing design, chamber and feeding channels. The locations of welding zones in the die are clearly predicted. It allows to modify the die design for better welding conditions and to provide optimal location of welding seams in the product. Die stress analysis shows the ways to extend the tool life by means of reducing of fatigue failure and selecting proper die materials as well as to correct the influence of the die deformation on the material flow. The described model is implemented in an especially dedicated program QForm-Extrusion that effectively simulates the extrusion of hollow and solid profiles with very high elongation ratios. The experimental verification of the model is illustrated by model and industrial experiments as well as by series of case studies performed in production environment.

• Periodical: Key Engineering Materials (Volumes 504-506)
• Pages: 505-510
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.504-506.505
• Online since: February 2012
• Authors: Nikolay Biba, Sergei Stebunov, Andrey Lishny
• Keywords: Aluminum (Al), Dies, Extrusion, Finite Element Method (FEM), Profile, Simulation

References

[1] N. Biba, S. Stebunov, A. Vlasov, Application of QForm Program for Improvement of the Die Design and Profile Extrusion Technology in Proceedings of the Ninth International Aluminum Extrusion Technology Seminar & Exposition, Orlando, USA, (2008)

[2] S. Stebunov, A. Lishnij, N. Biba, Development and industrial verification of QForm-Extrusion program for simulation profile extrusion in Proceeding of International Conference on Extrusion and Benchmark, Dortmund, Germany, 2009, pp.41-42.

DOI: 10.4028/www.scientific.net/kem.491.35

[3] A. Selvaggio, A. Segatori, A. Guzel, L. Donati, L. Tomesani, E. Tekkaya, Extrusion Benchmark 2011: Evaluation of different design strategies on process conditions, die deflection and seam weld quality in hollow profiles in Progress in Extrusion Technology and Simulation of Light Metal Alloys, Bologna, Italy, 2011, pp.1-10.

DOI: 10.4028/www.scientific.net/kem.491.1

[4] N. Biba, S. Stebunov, A. Lishnij, QForm-Extrusion data form scientific in Latest Advances in Extrusion Technology and Simulation and 4th Extrusion Benchmark, Bologna, Italy, 2011, pp.201-207.

DOI: 10.4028/www.scientific.net/kem.491.35

[5] S. Stebunov, N. Biba, A. Vlasov, A. Maximov, Thermally and Mechanically Coupled Simulation of Metal Forming Processes in Proceedings of the 10th International Conference on Technology of Plasticity, Aachen, Germany, 2011, pp.171-175.

[6] Information on www.qform3d.com.

[7] N. Biba, S. Stebunov, A. Lishnij, Influence of contact friction conditions on thin profile simulation accuracy in Progress in Extrusion Technology and Simulation of Light Metal Alloys, Bologna, Italy, 2011, pp.35-42.

DOI: 10.4028/www.scientific.net/kem.491.35

[8] D. Pietzka, N. Ben Khalifa, L.Donati, L. Tomesani, E. Tekkaya, Extrusion Benchmark 2009. Experimental analysis of deflection in extruded dies in Advances on Hot Extrusion and Simulation of Light Alloys, Dortmund, Germany, 2009, pp.19-26.

DOI: 10.4028/www.scientific.net/kem.424.19
