Analysis of the Pressure and Carrying Capacity of the Friction Pair Fluid-Film for the High Parameter Bellows Mechanical Seal

Abstract:

In this research, by based on the computational fluid dynamics (CFD) numerical theory, using the Standard-Turbulence model and the Standard-Wall function, the fluid-film between the clearance of the sealing ring friction pair for the bellows mechanical seal under such the high-temperature, high-pressure, high-speed as complex working conditions was numerically simulated, the pressure fluid and the relationship of the carrying-capacity of the fluid-film between the pressure inlet of seal cavity and the width of the fluid-film, and the results of the numerical analysis was compared with the theoretical value. The researching results provide the scientific basis for the optimization designing of the high parameter bellows mechanical seals.

• Periodical: Key Engineering Materials (Volume 522)
• Pages: 441-446
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.522.441
• Online since: August 2012
• Authors: Qiang Gao, Mutellip Ahmat, Li Chao Ren, Jing Luo
• Keywords: Carrying Capacity, Computational Fluid Dynamics (CFD), Fluid Pressure Field, Friction Pair

References

[1] F.J. Wang: Computational Fluid Dynamics Analysis (Tsinghua University Press, China 2009 ). (In Chinese).

[2] B.Q. Gu: Fluid Mechanics. Science and Culture (Publishing House, China 2002). (In Chinese).

[3] J.F. Zhou: Effects of Thermal Fluid Power of Mechanical Seal, (2006), (In Chinese).

[4] H.L. Liu, L. Dong: Fluid Mechanics, , Vol. 38 (2010) No. 4. pp.32-37. (In Chinese).

[5] Braun M.J., Kudriavtsev V.V., Hendricks R. C: The 9th International Symposium on Transport Phenomena and Dynamics of Rotating Machinery, (Hawaii, 2002) Vol. 10-14 (2002).

[6] Z.G. Luan, Khonsari M. M: Journal of Tribology, Vol. 128 (2006), pp.559-565.
