New Non-Contact Measurement of Small inside-Diameter Using Tandem Low-Coherence Interferometer and Optical Fiber Devices

Abstract:

Recently, manufacturing techniques of small-scale products have been improved. As a result, precise measurement is required of small inside diameters, for example, of engine nozzles. However, an in situ measurement and measurement system for small-sized products has yet to be fully established. In this research, a contactless technique to measure small inside diameters is proposed. This new method uses tandem low-coherence interferometry and an optical fiber cut at an angle of 45°. This optical fiber is up to 30 μm in diameter and is used as a probe. Our objective is to measure holes as small as 50-μm inside diameter with an accuracy of 100 nm. In the present paper, we report on the measurement principle, calculate the measurement uncertainty and show that experimental measurements can be obtained of small-size holes up to 300-μm inside diameter with an accuracy of 100 nm.

You might also be interested in these eBooks

Emerging Technology in Precision Engineering XIV

View Preview

Info:

Periodical:

Key Engineering Materials (Volumes 523-524)

Pages:

871-876

DOI:

https://doi.org/10.4028/www.scientific.net/KEM.523-524.871

Citation:

Cite this paper

Online since:

November 2012

Authors:

Kenta Matsui, Hirokazu Matsumoto, Satoru Takahashi, Kiyoshi Takamasu

Keywords:

45°-Cut Optical Fiber, Low Coherence Interferometer, Non-Contact Measurement, Small-Size Diameter Measurement

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] H. Murakami, A. Katsuki H. Onikura, T. Sajima, N. Kawagoishi, E. Kondo, Development of a System for Measuring Micro Hole Accuracy Using an Optical Fiber Probe, Journal of Advanced Mechanical Design, Systems, and Manufacturing, Vol. 4, No. 5(2010).

DOI: 10.1299/jamdsm.4.995

Google Scholar

[2] Lin, B. J, Electrical Measurement of Submicrometer Contact Holes, IEEE TRANSACTIONS ON SEMICONDUCTOK MANUFACTURING, Vol. 2, No. 3, August IYXY.

Google Scholar

[3] H. Matsumoto, K. Sasaki, Remote Measurements of Practical Length Standards Using Optical Fiber Networks and Low-Coherence Interferometers, Japanese Journal of Applied Physics, Vol. 47, No. 11, pp.8590-8594, (2008).

DOI: 10.1143/jjap.47.8590

Google Scholar

[4] N. Ohsawa, H. Matsumoto, A. Hirai, M. Arai, T. Shimizu, T. Kikuchi, Non-Contact Remote Measurements of Ring Gauge Using a Low-Coherence Interferometer, 10th International Symposium on Measurement and Quality Control 2010, September 5-9.

Google Scholar
