Comparisons of High-Temperature Structural Analysis Results on the Medium-Scale PHE Prototype under the Steady-State and Trip Conditions of a Small-Scale Gas Loop

Abstract:

PHE (Process Heat Exchanger) is a key component for transferring the high-temperature heat generated from a VHTR (Very High Temperature Reactor) to a chemical reaction for massive production of hydrogen. Recently, Korea Atomic Energy Research Institute (KAERI) has manufactured a medium-scale PHE prototype made of Hastelloy-X of high-temperature alloy and a performance test on the PHE prototype is scheduled in a small-scale nitrogen gas loop established at KAERI. In this study, in order to evaluate the high-temperature structural integrity of the PHE prototype under the steady-state and trip conditions of the gas loop before the performance test on the PHE prototype, elastic and elastic-plastic structural analyses on the PHE prototype were carried out and the analyses results were compared each other.

• Periodical: Key Engineering Materials (Volumes 525-526)
• Pages: 5-8
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.525-526.5
• Online since: November 2012
• Authors: Kee Nam Song, S.D. Hong, H.Y. Park
• Keywords: High-Temperature Structure Analysis, Medium-Scale Process Heat Exchanger (PHE), Small-Scale Gas Loop, Steady-State, Trip Condition, Very High Temperature Reactor (VHTR)

References

[1] Chang, J. H. et al., Nuclear Engineering and Technology, Vol. 39, No. 2 (2007), p.111.

[2] US DOE, Financial Assistance Funding Opportunity Announcement, NGNP Program (2009).

[3] AREVA, NGNP with Hydrogen Production Pre-conceptual Design Studies Report, Doc. No. 1209052076-000 (2007).

[4] Kim, Y. W., R.O. Korea patent # 10-0877574 (2008).

[5] I-DEAS/TMG Analysis User Manual Version 6. 1 (2009).

[7] ABAQUS Analysis User's Manual, Version 6. 8 (2009).

[7] Hastelloy-X Alloy website, www. haynesintl. com.

[8] Song, K. N., ICFDM 2012 Papae #152 (2012).
