Coupled Thermo-Mechanical-Metallurgical Analysis of an Hot Forging Process of Titanium Alloy

Abstract:

In the present paper a numerical FEM model for the analysis of a forming process of a complex shape component is presented. The model, developed using the commercial implicit code DEFORM™, can take into account both the thermo-mechanical evolution and the microstructural evolution of the considered material. In this case the Ti-6Al-4V titanium alloy was because it was possible to carry out a very good characterization into a FEM ambient. In particular the code can calculate the phase distribution of the main phases of the alloy as consequence of the thermo-mechanical history of the material during a hot forging process. At the end of the simulation the output data was showing to analyze the validity and the quality of the model by a numerical point of view.

• Periodical: Key Engineering Materials (Volumes 554-557)
• Pages: 638-646
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.554-557.638
• Online since: June 2013
• Authors: Antonino Ducato, Livan Fratini, Fabrizio Micari
• Keywords: Finite Element Method (FEM), Thermo-Mechanical-Metallurgical, Ti6Al4V, Titanium Alloy

References

[1] H.J.M. Geijselaers, H. Huétink, Thermo-Mechanical Analysis with Phase Transformations, Mechanical Engineering, University of Twente, POBox 217, 7500AE Enschede, the Netherlands.

[2] C. Angelet de Saracibar, M. Cervera, M. Chiumenti, On the formulation of coupled thermoplastic problems woth phase-change, Internationl journal of plasticity 15, (1999), 1-34.

DOI: 10.1016/s0749-6419(98)00055-2

[3] Deform™, Scientific Forming Technologies Corporation, Columbus, Ohio.

[4] J.I. Qazi, O.N. Senkov, J. Rahim, A. Genc, F.H. Froes, Phase Transformations in Ti-6Al-4V–xH Alloys, Metallurgical and materials transactions 32A, (2001), 2463.

DOI: 10.1007/s11661-001-0035-8

[5] M. Coret, S. Calloch, A. Combescure, Experimental study of the phase transformation plasticity of 16MND5 low carbon steel under multiaxial loading, International journal of plasticity18, (2002), 1707-1727.

DOI: 10.1016/s0749-6419(01)00067-5

[6] JMatPro Demo version, Sente Software Ltd. Surrey Technology Centre 40 Occam Road GU2 7YG United Kingdom.

[7] S. Bruschi, S. Poggio, F. Quadrini, M.E. Tata - Workability of Ti–6Al–4V alloy at high temperatures and strain rates - Materials Letters Volume 58, Issues 27–28, November (2004), Pages 3622–3629.

DOI: 10.1016/j.matlet.2004.06.058

[8] W. Sha, S. Malinov, Titanium alloys: modelling of microstructure, properties and applications, CRC Press, Boca Raton Boston New York Washington, DC.

[9] T. Altan, Cold and Hot Forging: Fundamentals and Applications, ERC/NSM, Ohio State University Gracious Ngaile, North Carolina State University Gangshu Shen, Ladish Company, Inc. (2005) ASM International.

DOI: 10.31399/asm.tb.chffa.9781627083003

[10] Handbook of workability and process design, (2003) ASM International.

[11] G. Buffa , A. Ducato ,L. Fratini, Numerical procedure for residual stresses prediction in friction stir welding, Finite Elements in Analysis and Design, 47(2011), 470–476.

DOI: 10.1016/j.finel.2010.12.018

[12] G. Buffa , A. Ducato ,L. Fratini, F. Micari, Numerical prediction of Biphasic Titanium Alloys Microstructure in Hot Forging Operations, 14th international conference of Metal Forming, (2012).
