EDM Surface Strengthening Research on Rubber Mold

Abstract:

Spark deposition technology is a kind of important means on rubber mold surface strengthening and repair .The temperature field for 2A12 Aluminum Alloy during EDM surface strengthening is simulated and analyzed through establishing proper finite element model based on finite element software. The results show that: During the strengthening, temperature field is mainly concentrated on the surface of work-piece and has little influence on the internal of work-piece. The temperature field of the surface of work-piece has the dynamic effects, which moves with the movement of the strengthening point and becomes stable as time passes. During the strengthening, the temperature for nodes on the surface decreases slowly after rising rapidly, and the strengthening point has the highest temperature. The barrier of the insulated boundary has a great influence on the distribution of temperature.

• Periodical: Key Engineering Materials (Volume 561)
• Pages: 291-295
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.561.291
• Online since: July 2013
• Authors: Jie Liu, Zuo Jing Liu, Ming Zhang
• Keywords: 2A12 Aluminum Alloy, EDM Surface Strengthening, Finite Element Analysis (FEA), Rubber Mold, Temperature Field

References

[1] Guo feng, et, Research on the structure and properties of LY12 Aluminum Alloy [J]. Material Engineering, 2010, 1: 28-31.

[2] Zhang Ming, Han Rong juan. Research on the Temperature Field of EDM Surface Strengthening in Gas Medium Based on ANSYS [J]. Journal of Qingdao University of Science and Technology: Nature Science, 2010, 31(1): 76-79.

[3] Pan Fu sheng, Zhang Ding fei, et, Aluminum Alloy and Application [M]. Beijing: Chemical Industry Press, 2005.

[4] Gao De dong. Prediction of Micro-EDM Surface Profile Based on Thermal Simulation [J]. Manufacturing Technology and Machine Tool, 2008, 11:49-53.

[5] Xu Chao, Sun Feng lian, et, Stress Analysis on Diamond and Brazed joint of cemented carbide [J]. Transactions of the China Welding Institution, 2003, 24(2): 47-50.

[6] Zhao Guo hua,et, Using ANSYS to Simulate Impact Stress Field of Composite Laminate Plate [J].Machine Tool and Hydraulics, 2005,5: 159-161.

[7] Chu Dang sheng, TONG Hong shu, et, Analysis of Tectonic Stress Field Molding Based on ANSYS [J]. Journal of An hui University of Science and Technology: Nature Science, 2008, 28(1): 16-19.
