Vibration-Based Structural Health Monitoring of a Simulated Beam with a Breathing Crack

Abstract:

Cracking is a common type of failure in machines and structures. Cracks must be detected at an early stage before catastrophic failure. In structural health monitoring, changes in the vibration characteristics of the structure can be utilized in damage detection. A fatigue crack with alternating contact and non-contact phases results in a non-linear behaviour. This type of damage was simulated with a finite element model of a simply supported beam. The structure was monitored with a sensor array measuring transverse accelerations under random excitation. The objective was to determine the smallest crack length that can be detected. The effect of the sensor locations was also studied. Damage detection was performed using the generalized likelihood ratio test (GLRT) in time domain followed by principal component analysis (PCA). Extreme value statistics (EVS) were used for novelty detection. It was found that a crack in the bottom of the midspan could be detected once the crack length exceeded 10% of the beam height. The crack was correctly localized using the monitoring data.

• Periodical: Key Engineering Materials (Volumes 569-570)
• Pages: 1093-1100
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.569-570.1093
• Online since: July 2013
• Authors: Jyrki Kullaa, Kari Santaoja, Anthony Eymery
• Keywords: Breathing Crack, Damage Detection, Damage Localization, Structural Health Monitoring (SHM)

References

[1] S. Vanlanduit, E. Parloo, P. Guillaume, On-line detection of fatigue cracks using an automatic mode tracking technique, First European Workshop on Structural Health Monitoring (SHM 2002), D.L. Balageas (ed. ), Paris, France, July 10–12, 2002. Onera. DEStech, p.734.

[2] S. Vanlanduit, E. Parloo, P. Guillaume, An on-line combined linear–nonlinear fatigue crack detection technique, NDT & E International 37 (2004) 41–45.

DOI: 10.1016/s0963-8695(03)00094-x

[3] V.K. Nguyen, O.A. Olatunbosun, A proposed method for fatigue crack detection and monitoring using the breathing crack phenomenon and wavelet analysis, Journal of Mechanics of Materials and Structures 2 (2007) 399–420.

DOI: 10.2140/jomms.2007.2.399

[4] V. Zabel, W. Rücker, Detection of a Fatigue Crack by Vibration Tests, Proceedings of the IMAC-XXVII, February 9–12, 2009 Orlando, Florida USA, Society for Experimental Mechanics.

[5] I. Abu-Mahfouz, Vibration based diagnostics of fatigue damage, Proceedings of the IMAC-XXVII, January 31–February 3, 2005, Orlando, Florida, USA, Society for Experimental Mechanics.

[6] S.L. Tsyfansky, V.I. Beresnevich, Detection of fatigue cracks in flexible geometrically non-linear bars by vibration monitoring, Journal of Sound and Vibration 213 (1998) 159–168.

DOI: 10.1006/jsvi.1998.1502

[7] P. Razi, R.A. Esmaeel, F. Taheri, Application of a robust vibration-based non-destructive method for detection of fatigue cracks in structures, Smart Materials and Structures 20 (2011) 115017 doi: 10. 1088/0964-1726/20/11/115017.

DOI: 10.1088/0964-1726/20/11/115017

[8] R.W. Clough, J. Penzien, Dynamics of structures. 2nd edition, McGraw-Hill, New York (1993).

[9] J. Kullaa, Sensor validation using minimum mean square error estimation, Mechanical Systems and Signal Processing 24 (2010), 1444–1457.

DOI: 10.1016/j.ymssp.2009.12.001

[10] M. Basseville, I.V. Nikiforov, Detection of abrupt changes — Theory and application, Prentice-Hall, Englewood Cliffs, NJ (1993).

[11] S.M. Kay, Fundamentals of statistical signal processing. Detection theory, Prentice-Hall, Upper Saddle River, NJ (1998).

[12] S. Sharma, Applied multivariate techniques, John Wiley, New York (1996).

[13] E. Castillo, Extreme value theory in engineering, San Diego, CA, Academic Press, (1988).

[14] K. Worden, D. Allen, H. Sohn, C.R. Farrar, Damage detection in mechanical structures using extreme value statistics, in: SPIE Proceedings, Vol. 4693, 9th Annual International Symposium on Smart Structures and Materials, San Diego, CA, 2002, p.289.

DOI: 10.1117/12.475226

[15] D.C. Montgomery, Introduction to statistical quality control, 3rd edition, John Wiley, New York (1997).
