Development and Challenge of the Vehicle and Highway Bridges Dynamic Interaction

Abstract:

With the development of long-span flexible bridges and the increase of highway transportation, both the dynamic responses of highway bridges under high-speed and heavy vehicles and the safety control of vehicles have deserved general concerns. First, this paper briefly discussed some researches on coupling vibration of vehicle and highway-bridges, then roundly summarized main research achievements accounting on the vehicle analytical model, bridge analytical model, surface roughness of road, numerical method of vehicle-bridge coupling vibration and some other aspects. Meanwhile, some research trends and challenge on vehicle and bridge dynamic interaction in engineering application were pointed out.

• Periodical: Key Engineering Materials (Volume 574)
• Pages: 135-150
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.574.135
• Online since: September 2013
• Authors: Jia Feng Liu, Yan Li
• Keywords: Bridge Coupled Vibration, Development Status, Highway Bridge, Numerical Analysis, Vehicle Coupled Vibration, Vehicle Model
