High Pressure Pneumatic Control Valve Performance Test System

Abstract:

As a pressure regulating component, pneumatic control valve has been widely used in control system. The stability of its performance not only concerns the control precision, but also has direct influence on the systems normal operation. Thus, a test on the valves characteristics before putting into use is rather important. According to analysis of testing requirements, this paper determined the overall program of this pneumatic measurement system, designed the gas-circuit, provided specialized software for measurement, and developed an automatic test system. The experimental data shows the system is with high precision and can satisfy the needs of valve test well.

• Periodical: Key Engineering Materials (Volumes 579-580)
• Pages: 295-299
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.579-580.295
• Online since: September 2013
• Authors: Xu Dong Pan, Guang Lin Wang, Guo Yu Shen, Rui Qi Song
• Keywords: Performance Test, Pressure Reducer, Pressure Stabilizer, Valve

References

[1] Y.K. Wu: Hydraulic and Pneumatic Technology (People's Posts and Telecommunications Press, China 2009), p.149. (In Chinese).

[2] X. G: Missiles and Space Vehicles, Vol. 3 (2006), pp.56-61. (In Chinese).

[3] Liquid Rocket Pressure Regulators, Relief Valves, Check Valves, Burst Disks and Explosive Valves, NASA SP-8080 MARCH (1973).

[4] W.Y. Zhou and Y.L. Zhang: Journal of Astronautics, Vol. 31 (2010) No. 1, pp.173-177. (In Chinese).

[5] J.H. Ma and F.H. Qian: Industrial Instrumentation & Automation, Vol. 1 (1990), pp.36-38. (In Chinese).

[6] F. Dong and J. Zhou: Rocket Propulsion, Vol. 31 (2005) No. 2, pp.59-62. (In Chinese).
