Information Modeling and Visualization of Assembly Fat Model for Large-Scale Product

Abstract:

Assembly processes are very complex and hard to setup in one-time for large-scale products. Much assembly information is produced in various assembly processes and such information has not integrated or considered for next assembly processes. This leads to problems of deciding manufacturing tolerance of productions quality in the final assembly process. An object-oriented assembly information model and visualization for VAFM (Virtual Assembly Fat Model), is presented in the paper. The information modeling for assembly processes considers not only geometry data, but also non-geometry information, and those information produced by assembly process evolve, mature and derived during the whole assembly process. The paper presents modeling language based on XML and distributed storage based BSON for assembly object. The visualization of VAFM is also presented.

• Periodical: Key Engineering Materials (Volumes 579-580)
• Pages: 711-718
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.579-580.711
• Online since: September 2013
• Authors: Jin Song Bao, Dian Liang Wu, Qing He Cheng, Jian Hui Pan
• Keywords: BSON, Fat Model, Large-Scale Product, Object-Oriented (OO), Visualization

References

[1] W. Shen and J.P. Barthes: Description and Applications of an Object-Oriented Model PDM, Modeling Complex Data for Creating Information: Real and Virtual Objects, eds., Dubois J.E. & Gershon N., Spinger Verlag, (1995), pp.15-24.

DOI: 10.1007/978-3-642-80199-0_3

[2] S.R. Gorti, A. Gupta, G.J. Kim, R.D. Sriram and A. Wong: Computer-Aided Design, Vol. 30 (1998) No. 7 , pp.489-501.

DOI: 10.1016/s0010-4485(97)00087-0

[3] D. Pugliese, G. Colombo and M.S. Spurio: Proceedings of the 14th CIRP Conference on Life Cycle Engineering (Tokyo, Japan, June 11th–13th, 2007), pp.131-136.

[4] D.N. Šormaz, J.A. Arumugam, R.S. Harihara, P. Chintankumar and N. Narender: Robotics and Computer-Integrated Manufacturing, Vol. 26 (2010) No. 6, pp.583-595.

DOI: 10.1016/j.rcim.2010.07.014

[5] X. Li and S.B. Yoo: Computers in Industry, Vol. 62 (2011) No. 3, pp.281-291.

[6] S.Y. Mamadou and M. Christian: Journal of Engineering Design, Vol. 22 (2011) No. 6, pp.387-406.

[7] R. Barbau and S. Krima: Computer-Aided Design, Vol. 44 (2012) No. 6, pp.575-590.

[8] V. K. Vaishnavi, S. Purao and J. Liegle: Information Sciences, Vol. 177 (2007) No. 2, pp.587-606.

DOI: 10.1016/j.ins.2006.06.002

[9] H. Bergen and S. Kristina: Journal of Mechanical Design, Transactions of the ASME, Vol. 134 (2012) No. 2, pp.1-14.

[10] J.S. Bao, Y.C. Yang and D.L. Wu: Proceedings of the CDVE 2012 (OSAKA, Japan, Sept. 2th-6th), pp.187-194.

[11] 3DXML User Guide 4. 3 on http: /www. 3ds. com/3dxml.

[12] OpenXML on http: /openxmldeveloper. org.

[13] MongoDB on http: /www. mongodb. org.
