Evaluation Study of Subgrade Service Condition Based on Falling Weight Deflectometer

Abstract:

To make appropriate rehabilitation decisions, determining subgrade modulus of the existing semi-rigid asphalt pavements is a crucial task for highway engineers. Falling Weight Deflectometer (FWD), as a nondestructive testing technology, is an effective tool to determine subgrade modulus. The objective of this study was to establish a method to predict subgrade modulus of asphalt pavements based on Falling Weight Deflectometer. With the basic theory of structure dynamics, the finite element model of the asphalt pavement was established to generate a synthetic database of surface dynamic deflection basin parameter (DBP) indicators. Then, the relationship between DBP indicators and subgrade modulus was discussed and the prediction function for determining subgrade modulus was established. The analysis results demonstrate that subgrade modulus can be predicted by the direct deflection indicator d₉, shape indicator F₈ and structure layer thickness and the predicted precision is satisfied. The relative error between the theoretical value and the predicted values ranges from-13.2% to +15.56% according to subgrade modulus. The mean value of absolute relative error is 2.36%. The research results provide a technology supports to popularize FWD testing technology applied in performing subgrade structure performance evaluation.

• Periodical: Key Engineering Materials (Volumes 579-580)
• Pages: 831-834
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.579-580.831
• Online since: September 2013
• Authors: Xin Qiu, Qing Yang, Xiao Hua Luo, Bing Ru Wang
• Keywords: Falling Weight Deflectometer, Modulus Parameter, Performance Evaluation, Subgrade

References

[1] P. Ullidtz: Transportation Research Record: Journal of the Transportation Research Board, Vol. 1482 (1995), pp.92-99.

[2] W. Uddin and Z. Pan: Proc. 8th International Conference on Asphalt Pavements (Copenhagen 1997), Vol. 1, pp.41-49.

[3] B. XU: Assessing Pavement Layer Condition Using FWD Deflection Data (Ph.D., North Carolina State of University, USA 2000), pp.42-43.
