CFD Analysis of Cryogenic Oil Mist of Milling Cutters with Different Interior Channels

Abstract:

In the present research, a model of the cryogenic oil mist flow field of milling cutters with different interior oil channels was conducted to determine the effects of rotational speed, temperature and flow of cold air. For the milling cutters with single direct hole and double direct holes, the increase of the rotational speed has little effect on the velocity and temperature of the measuring points at different distances along the milling cutters. For the milling cutter with double direct holes the separated streamlines of double direct holes are nearer with the rise of the distance because of the viscidity of cutting fluid. When the distance exceeds 5mm, the separated streamlines combine with each other. For the milling cutter with double helical holes the streamlines of cold air present irregularly. At last, some of the simulated results were validated.

• Periodical: Key Engineering Materials (Volumes 589-590)
• Pages: 317-322
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.589-590.317
• Online since: October 2013
• Authors: Lin Tao Zou, Song Zhang, Wei Dong Chen, Guo Qiang Zhao, Bin Zhao
• Keywords: CFD Analysis, Milling Cutters, Temperature, Velocity

References

[1] N.R. Dhar, M.W. Islam, S. Islam, M.A.H. Mithu: J. Mater. Proc. Tech. Vol. 171 (2006), p.93.

[2] Y. Kamata, T. Obikawa: J. Mater. Proc. Tech. Vol. 192-193 (2007), p.281.

[3] M. Chen, L. Jiang, B.W. Shi, L.Q. Liu and Q.L. An: Mater. Sci. Forum Vol. 723 (2012), p.113.

[4] H.J. Pei, C.G. Shen, W.J. Zheng and G.C. Wang: Adv. Mater. Res. Vol. 135 (2010), p.462.

[5] W.J. Zheng, H.J. Pei, G.C. Wang and C.G. Shen: Adv. Mater. Res. Vol. 188 (2011), p.61.
