Experimental and Numerical Investigation of Thin Liquid Layers at Curved Solid Edges

Abstract:

The knowledge of the behavior of thin liquid layers on solid surfaces is of fundamental interest as far as basic research or applications like technical coating or lubrication processes are concerned. The subject is currently getting more important, particularly due to the increasing requirements of thin liquid layer functionalities. We therefore studied the development of the liquid layer thickness distribution field as well as the liquid layer disturbance propagation on a plane solid surface in the vicinity of a curved solid surface experimentally and numerically using LIF (Laser-induced Fluorescence) and CFD (Computational Fluid Dynamics), respectively. The investigation focusses on the influence of the initial layer thickness and solid surface curvature as well as liquid properties like viscosity and surface tension on the film behavior, especially close to solid edges. Experimental and numerical results are shown pointing out relevant quantities for disturbance propagation and validation.

You might also be interested in these eBooks

Progress in Mechanical Engineering and Technology

View Preview

Info:

Periodical:

Key Engineering Materials (Volume 597)

Pages:

51-62

DOI:

https://doi.org/10.4028/www.scientific.net/KEM.597.51

Citation:

Cite this paper

Online since:

December 2013

Authors:

Oliver Sommer*, Daniel Moller, Günter Wozniak

Keywords:

Computational Fluid Dynamics (CFD), Curved Surface, Laser Induced Fluorescence, Thickness Distribution, Thin Liquid Layer

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

* - Corresponding Author

References

[1] T.G. Mezger, Das Rheologie Handbuch, Vincentz Network, Hannover (2010).

Google Scholar

[2] G. Meichsner, T.G. Mezger, J. Schröder, Lackeigenschaften messen und steuern. Coatings Compendien, Vincentz Network, Hannover (2003).

DOI: 10.1515/9783748600190

Google Scholar

[3] P. Mischke, Filmbildung. Filmbildung in modernen Lacksystemen. Vincentz Network, Hannover (2007).

Google Scholar

[4] T. Glawdel et al., Photobleaching absorbed Rhodamine B to improve temperature measurements in PDMS microchannels. Lab on Chip, Vol. 9, 171-174 (2009).

DOI: 10.1039/b805172k

Google Scholar

[5] A. Petracci, R. Delfos, J. Westerweel, Combined PIV/LIF measurements in a Rayleigh-Bénard convection cell. 13th Int. Symp. on Applications of Laser Techniques to Fluid Mechanics, Lisbon, Portugal (2006).

Google Scholar

[6] I. Ausner, A. Hoffmann, J. -U. Repke and G. Wozny, Experimentelle und numerische Untersuchungen mehrphasiger Filmströmungen. Chemie Ingenieur Technik, Vol. 77, No. 6, 735-741 (2005).

DOI: 10.1002/cite.200407099

Google Scholar

[7] I. Ausner, Experimentelle Untersuchungen mehrphasiger Filmströmungen. Dissertation, TU Berlin (2006).

Google Scholar

[8] J.U. Brackbill, D.B. Kothe and C. Zemach, A Continuum Method for Modeling Surface Tension, Journal of Computational Physics, Vol. 100, 335-354 (1992).

DOI: 10.1016/0021-9991(92)90240-y

Google Scholar
