Structural and Dielectric Properties of Rare Earth (Y, Ho) Doped Ba_0.95Ca_0.05Ti_0.85Zr_0.15O₃ Ceramics

Abstract:

Ba_0.95Ca_0.05Ti_0.85Zr_0.15O₃ (BCTZ) dielectric ceramics were fabricated by traditional solid-state method, using barium carbonate, calcium carbonate, titanium dioxide and zirconium dioxide as the starting materials. Rare earth dopants have a significant influence on the dielectric properties of BCTZ ceramics. The doping effects of Y and Ho with different content on the dielectric properties and structure were studied respectively. The results reveal that the effects of Y and Ho are similar, they perfer to occpy B site, and they move the dielectric peak to lower temperature, widen the peak and increase the insulation resistivity, thus improve the dielectric properties obviously. The effects were investigated by X-ray diffraction, scanning electron microscope, and dielectric property measurements. After rare earth elements-doping, the BCTZ ceramics satify the Y5V EIA specifications, mainly due to the change of structure. The BCTZ dielectric ceramics with high permittivity over 10,000, high insulation resistivity over 10¹² Ωcm, low dielectric loss less than 1%, can be applied in multilayer ceramic capacitors (MLCCs).

• Periodical: Key Engineering Materials (Volumes 602-603)
• Pages: 728-733
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.602-603.728
• Online since: March 2014
• Authors: Zheng Bo Shen, Xiao Hui Wang*, Hui Ling Gong, Long Tu Li
• Keywords: Dielectric Property, Rare Earth Dopants, Solid-State Method, Y5V

References

[1] B. Jaffe, W. Cook, and H. Jaffe, Piezoelectric Ceramics, Academic, London, (1971).

[2] A. J. Moulson, J. M. Herbert, Electroceramics: Materials, Properties, Applications, Second Edition, John Wiley & Sons, New York, (2003).

[3] G.H. Jonker, E.E. Havinga, The influence of foreign ions on the crystal lattice of barium titanate, Mat. Res. Bull., 17(1982)345-350.

DOI: 10.1016/0025-5408(82)90083-6

[4] H. Kishi, N. Kohzu, J. Sugino, et al., The effect of rare-earth (La, Sm, Dy, Ho and Er) and Mg on the microstructure in BaTiO3, J. Eur. Ceram. Soc., 19(1999)1043-1046.

DOI: 10.1016/s0955-2219(98)00370-7

[5] K.J. Park, K. C. Hoon, Y. Y. Joo, et al., Doping behaviors of dysprosium, yttrium and holmium in BaTiO3 ceramics, J. Eur. Ceram. Soc., 29(2009)1735-1741.

[6] Y. X. Li, X. Yao, X. S. Wang, Y. B. Hao. Studies of dielectric properties of rare earth (Dy, Tb, Eu) doped barium titanate sintered in pure nitrogen, Ceram. Int., 38(2012)S29-S32.

DOI: 10.1016/j.ceramint.2011.04.042

[7] Y. Tsur, A. Hitomi, I. Scrymgeour, et al., Site occupancy of rare-earthcations in BaTiO3, Jan. J. Appl. Phys., 40(2001)255–258.

[8] T. Murakami, TMiuashit, M. Nakahara, E. Sekine, Effect of Rare-Earth Ions on Electrical Conductivity of BaTiO3 Ceramics, J. Am. Ceram. Soc., 56(1973)294-297.

DOI: 10.1111/j.1151-2916.1973.tb12498.x

[9] G.V. Lewis, C.R.A. Catlow, Defect studies of doped and undoped barium titanate using computer simulation techniques. J. Phys. Chem. Solids., 47(1986)89-97.

DOI: 10.1016/0022-3697(86)90182-4

[10] L.A. Xue, Y. Chen, R.J. Brook, The influence of ionic radii on the incorporation of trivalent dopants into BaTiO3, Mater. Sci. Eng., B, 1(1988)193-201.

DOI: 10.1016/0921-5107(88)90019-0

[11] J. Zhi, C. Ang, Z. Yu, et al., Incorporation of Yttrium in Barium Titanate Ceramics,J. Am. Ceram. Soc., 82(1999)1345-1348.

[12] K. Albertsen, D. Hennings, O. Steigelmann, Donor-acceptor charge complex formation in barium titanate ceramics: role of firing atmosphere. J. electroceram., 2 (1998)193-198.

[13] G. F. Yao, X. H. Wang, H. L. Gong, et al, Preparation and Characterization of X8R Fine-Grained Dielectric Ceramics, Jpn.J. Appl. Phys., 50. 12 (2011)1502.

DOI: 10.1143/jjap.50.121502
