Controlling Penetration Depth in Projection Stereolithography by Adjusting the Operation Wavelength

Abstract:

In projection stereolithography, the cure depth and thereby the layer thickness in the manufacturing process may be varied by changing the operation wavelength. The change can be made even in the middle of the manufacturing process, which opens up possibilities for additional flexibility and speed-up of the process.In this paper, we investigate how the penetration depth of the curing light in the resin depends on the wavelength. The measurements were performed for wavelengths between 400 nm and 550 nm using a standard commercial resin. The penetration depth was found to almost double when moving from the short wavelengths to the long ones.

• Periodical: Key Engineering Materials (Volumes 611-612)
• Pages: 756-762
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.611-612.756
• Online since: May 2014
• Authors: Pekka Lehtinen*, Santeri Laurila, Matti Kaivola, Jouni Partanen
• Keywords: Layer Thickness, Penetration Depth, Projection Stereolithography, Resin, Stereolithography

References

[1] C. Sun, N. Fang and X. Zhang: Projection micro-stereolithography using digital micro-mirror dynamic mask, Sensors and Actuators A: Physical, Vol. 121, Issue 1, pp.113-120, Elsevier (2005).

DOI: 10.1016/j.sna.2004.12.011

[2] A. Bertsch, J. Jézéquel and J. André: Study of the spatial resolution of a new 3D microfabrication process: the microstereophotolithography using a dynamic mask-generator technique, Journal of Photochemistry and Photobiology A: Chemistry, Vol. 107, pp.275-281, Elsevier (1997).

DOI: 10.1016/s1010-6030(96)04585-6

[3] X. Zhang, X. Jiang and C. Sun: Micro-stereolithography of polymeric and ceramic microstructures, Sensors and Actuators A: Physical, Vol. 77, Issue 2, pp.149-156, Elsevier (1999).

DOI: 10.1016/s0924-4247(99)00189-2

[4] K. Yamaguchi, T. Nakamoto and P. Abraha: Consideration on the accuracy of fabricating microstructures using UV laser induced polymerization, Proceedings of the 5th international symposium on micro-machine and human science, pp.171-176, Japan (1994).

DOI: 10.1109/ismmhs.1994.512919

[5] J. Choi, R. Wicker, S. Lee, K. Choi, C. Ha and I. Chung: Fabrication of 3D biocompatible/biodegradable micro-scaffolds using dynamic mask projection microstereolithography, Journal of Materials Processing Technology, Vol. 209, Issue 15, pp.5494-5503, Elsevier (2009).

DOI: 10.1016/j.jmatprotec.2009.05.004

[6] J. Choi, R. Wicker, S. Cho, C. Ha and S. Lee: Cure depth control for complex 3D microstructure fabrication in dynamic mask projection microstereolithography, Rapid Prototyping Journal, Vol. 15, Issue 1, pp.59-70, Emerald Group Publishing Limited (2009).

DOI: 10.1108/13552540910925072

[7] T. Nakamoto, K. Yamaguchi, P. Abraha and K. Mishima: Manufacturing of three-dimensional micro-parts by UV laser induced polymerization, Journal of Micromechanics and Microengineering, Vol. 6, No. 2, pp.240-253, IOP Publishing (1996).

DOI: 10.1088/0960-1317/6/2/006

[8] P. F. Jacobs: Rapid Prototyping & Manufacturing: Fundamentals of Stereolithography, Society of Manufacturing Engineers, United States (1992).

[9] A. Bertsch and P. Renaud, in: Stereolithography: Materials, Processes and Applications, edited by P. Bártolo, Microstereolithography, Chap. 4, Springer (2011).

[10] J. Lee, R. Prud'homme and I. Aksay: Cure depth in photopolymerization: Experiments and theory, Journal of Materials Research, Vol. 16, No. 12, Materials Research Society (2001).

[11] M. Zabti: Effects of Light Absorber on Micro Stereolithography Parts, Ph.D. thesis, University of Birmingham (2012).

[12] M. Cunico and J. Carvalho: Optimization of thick layers photopolymerization systems applying experimental and analytical approach, Rapid Prototyping Journal, Vol. 19, Issue 5, pp.337-343, Emerald Group Publishing Limited (2013).

DOI: 10.1108/rpj-11-2011-0119
