Research on Brake Shoe Eccentric Wear Mechanism by Analytical Method and Virtual Experiment

Abstract:

In this paper, a theoretical mechanical model for the brake shoe is set up according to the foundation brake unit of railway freight cars, and it indicates that the friction moment is the origin resulting in brake shoe eccentric wear. On this basis, the pressure distribution formula on the brake shoe is derived when the train brakes in forward and backward direction respectively. The analysis results show that if the wheel and the brake shoe are concentric, the ratio of the revolving-in end pressure to the revolving-out end pressure in wheel forward revolving is larger than that in wheel backward revolving. It is consistent with the phenomena that upper eccentric wear often appears on the brake shoe in practice. Further research reveals that the degree of the eccentric wear is determined by the braking force action style, which is the theoretical basis for the design revision. In addition, the RecurDyn Multi-body Dynamics software is used to build the rigid-flexible coupling dynamics model for the foundation brake unit. The simulation experiment verified the analysis result. The research outcome provides the theoretical basis and technical support for further design improvement of the foundation brake unit in railway freight cars.

• Periodical: Key Engineering Materials (Volume 620)
• Pages: 318-323
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.620.318
• Online since: August 2014
• Authors: Bao Zhang Qu*, Hong Bo Zhang, Bi Hong Lu, Zhen Ming Liu
• Keywords: Brake Shoe Wear, Foundation Brake Unit, Multi-Body Dynamics, Recurdyn

References

[1] J. H Liu, F. Li and W. B Nie: Railway Locomotive & Car, Vol. 26 (2006) No. 3. (In Chinese).

[2] J. M Yan and M. H Fu: Vehicle Engineering (China Railway Press, China 2011). (In Chinese).

[3] Z. Rao and J. B Peng: Train Braking (China Railway Press, China 2010). (In Chinese).

[4] M. L Qu: Harbin Railway Science and Technology for Reference and Application (2009), pp.18-19, (In Chinese).

[5] X. J Jiao, J. W Zhang and B. B Peng: RecurDyn Multi-body System Simulation Optimization Technology (Tsinghua University Press, China 2010). (In Chinese).

[6] J. S Huang: Based on Multi-body Dynamics Coupling Mechanism Analysis and Simulation Study (MS. Dalian Jiaotong University, China 2012). (In Chinese).

[7] B. H Lu, Y. Zhang, B. Z Qu, J. S Huang and Y. Liu: Key Engineering Materials Vol. 522 (2012), pp.467-471.
