Research on the NC Woodworking Curve Band Saw CAM

Abstract:

To achieve the processing program and simulation verification on NC Woodworking Curve Band Saw (WCBS) that facilitates the industrialization and practicality of the woodworking machinery, the articles proposes the CAM system modules by the analysis of its composition structure and working principle of the machine and the building-up of its kinematics model. The article also explains the basic functions for each module and develops the CAM systems of MJS1325 WCBS with the use of VC++ and OpenGL. Reading and analyzing the CAD work piece graphics files, the CAM systems is able to generate the NC program and realize the simulation of machining in whole visual process environment including saws, fixtures, belt saw and work piece, etc. The CAM systems pass the prototype test and see a favorable effect.

• Periodical: Key Engineering Materials (Volume 621)
• Pages: 101-106
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.621.101
• Online since: August 2014
• Authors: Yan Chen, Jian Hao Tan, Xiang Jun Zou, Li Juan Chen, Bo Li, Jing Wang
• Keywords: CAM, NC Program, NC Woodworking Curve Band Saw, Simulation

References

[1] Y. Ma: Forestry Machinery & Woodworking Equipment, Vol. 40 (2012), p.4.

[2] Z.J. Xu: Research of the numerical control system of numerical control curve saw (Nanjing Forestry University, China, 2005).

[3] J.W. Ding, N.Z. Had and Z.J. Xu: Wood Processing Machinery, Vol. 3 (2005), p.16.

[4] Y. Ma: Woodworking Machinery, Vol. 3 (2011), p.1.

[5] P.L. He, R. W Huang and H.S. Yu: China. Patent 201010252891. 1.

[6] W.B. Li: Research and development of CAD/CAM system of modern woodworking machinery (Beijing Forestry University, China, 2012).

[7] Y.L. Xiong, L.X. Tang and H. Ding: Fundamentals of robot techniques (Huazhong university of science, China, 1999).

[8] X.L. Luo, Z.L. Gu and K.B. Lei: physics mechanics & astronomy, Vol. 6 (2009), p.877.
