An Investigation of the Vibration Testing Method for Small Diameter Endmills

Abstract:

This paper introduced about the in-process vibration testing method for small diameter endmill. By this method, the natural frequency and modal parameters such as mass, damping, and stiffness of the milling tool can be determined in the milling process. An oscillation of the vibrator is controlled by the function generator to apply the impact force at the appropriate cutting period. The measurement setup can determine the compliance curve by the measurement signals of the exiting force and tool deformation. To evaluate the feasibility of the new method, vibration tests were performed on a square endmill which has the diameter of 4 mm in the milling on brass material. Results of vibration tests show that modal parameters of the specific vibration mode can be determined by the new developed method.

You might also be interested in these eBooks

Precision Engineering and Nanotechnology V

View Preview

Info:

Periodical:

Key Engineering Materials (Volume 625)

Pages:

134-139

DOI:

https://doi.org/10.4028/www.scientific.net/KEM.625.134

Citation:

Cite this paper

Online since:

August 2014

Authors:

Takenori Ono*

Keywords:

In-Process Testing, Micro Machining, Precision Machining, Vibration Control

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

* - Corresponding Author

References

[1] T. Matsumura, Y. Miyahara, T. Ono, Dynamic Characteristics in The Cutting Operations with Small Diameter End Mills, Journal of Advanced Mechanical Design, Systems, and Manufacturing Vol. 2, No. 4, 2008, pp.609-618.

DOI: 10.1299/jamdsm.2.609

Google Scholar

[2] T. Ono, A study on the vibration characteristics of the small diameter PCD coated milling tool , Conference proceedings of 12th International Conference of the European Society for Precision. Engineering and Nanotechnology (Euspen2012), Vol. 2, 2012, pp.275-278.

Google Scholar

[3] MATSUMURA, T. and HAIBARA, T.: Simulation of Dynamic Cutting Process in Milling Operation, Proceedings of the 4th Manufacturing & Machine Tool Conference of the Japan Society of Mechanical Engineers. , 2001, pp.173-174.

DOI: 10.1299/jsmemmt.2002.4.173

Google Scholar

[4] F. Koenigsberger, J. Tlusty, 1971, Machine Tool Structures, Vol. 1, Pergamon Press, UK.

Google Scholar
