Material Removal Rate Control in Open-Air Type Plasma Chemical Vaporization Machining by Pulse Width Modulation of Applied Power

Abstract:

Plasma chemical vaporization machining (PCVM) is an ultraprecise figuring technique for optical components without introducing the subsurface damage. In our previous study, the material removal volume was controlled by changing the scanning speed of the worktable. However, because of inertia of the worktable, a discrepancy between the theoretical scanning speed and the actual scanning speed will occur if the spatial change rate of speed is rapid. Therefore, we proposed the application of the pulse width modulation (PWM) control and the amplitude modulation (AM) control of the applied RF power to control the material removal rate (MRR). Experimental results showed that the relationship between the MRR and the average RF power had high linearity, the control range of the PWM control mode was from 0.19 x 10^-2mm³/min to 3.90 x 10^-2mm³/min (from 5% to 100%), which was much wider than that of the AM control mode.

You might also be interested in these eBooks

Precision Engineering and Nanotechnology V

View Preview

Info:

Periodical:

Key Engineering Materials (Volume 625)

Pages:

593-596

DOI:

https://doi.org/10.4028/www.scientific.net/KEM.625.593

Citation:

Cite this paper

Online since:

August 2014

Authors:

Yoshiki Takeda, Yuki Hata, Katsuyoshi Endo, Kazuya Yamamura*

Keywords:

Atmospheric Pressure Plasma, Plasma Etching, Pulse Width Modulation, Ultraprecision Figuring

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

* - Corresponding Author

References

[1] I. Eichentopf, G. Bohm and T. Arnold, Etching mechanisms during plasma jet machining of silicon carbide, Surf. Coat. Tech, 205 (2011) S430-S434.

DOI: 10.1016/j.surfcoat.2011.03.003

Google Scholar

[2] C. Zhao, X. Lu, P. He, P. Zhang, W. Sun, J. Zhang, F. Chen and F. Gou, CF3+ etching sillicon surface, A moleculaer dynamics study, Vacuum 86 (2012) 913-916.

DOI: 10.1016/j.vacuum.2011.06.003

Google Scholar

[3] L. De Chiffre, H. Kunzmann, G.N. Peggs and D.A. Lucca, Surface in Precision Engineering, Microengineering and Nanotechnoligy, Ann. CIRP, 52 (2003) 561-577.

DOI: 10.1016/s0007-8506(07)60204-2

Google Scholar

[4] K. Yamamura, S. Shimada and Y. Mori, Damage-free improvement of thickness uniformity of quartz crystal wafer by plasma chemical vaporization machining, Ann. CIRP, 57 (2008) 567-570.

DOI: 10.1016/j.cirp.2008.03.132

Google Scholar
