FE Analysis of Functionally Graded Material Plate during Debonding Case with Different Boundary Conditions

Abstract:

Functionally graded materials (FGMs) have become helpful in our engineering applications. Analysis of functionally graded material (FGM) plate during debonding case with different boundary conditions is the main purpose of this investigation. Elastic modulus (E) of functionally graded (FG) plate is assumed to vary continuously throughout the height of the plate, according the volume fraction of the constituent materials based on a modified sigmoid function, but the value of Poisson coefficient is constant. In this research, the finite element method (FEM) is used in order to show the shape of a plate made of FGM during debonding case with different boundary conditions. In the present investigation, the displacement value applied to the FGM plate is changed in order to find the relationship between the maximum von Mises stress and the displacement. Also, the relationship between the maximum shear stress and the displacement is carried out in the present work. The material gradient indexes of the FGM plate are changed from 1 to 10. The stress distributions around the debonding zone with all the material gradient indexes of the FGM plate are investigated in this work.

• Periodical: Key Engineering Materials (Volume 627)
• Pages: 57-60
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.627.57
• Online since: September 2014
• Authors: Wasim M.K. Helal*, Dong Yan Shi
• Keywords: Debonding, Finite Element Simulation, Functionally Graded Material (FGM), Plate

References

[1] Yamanoushi M., Koizumi M., Hiraii T. and Shiota I., in: Proceedings of the First International Symposium on Functionally Gradient Materials, Japan (1990).

[2] Koizumi M.:"The concept of FGM. Ceramic Transactions,"Functionally Gradient Materials, Vol.34, 3-10 (1993).

[3] Wasim M.K. Helal and D.Y. Shi: Indian Journal of Materials Science, Vol. 2014,7 P. (2014).
