Thermal Performance Characterization of a Modular System for Facade

Abstract:

The developed system corresponds to multifunctional prefabricated modular elements that combine an insulation layer with a cast coating material for exterior that can imitate stone or concrete. These systems need auxiliary elements of fixing to connect them mechanically to the structural wall of the building, in order to ensure its stability, using anchorage, profiles, rails, among others. The use of these systems connected to the coating interrupts the continuity of thermal insulation, causing additional heat losses through linear and point thermal bridges, having an detrimental effect on thermal performance of the system. The development of fixing of present multifunctional panels was based on the evaluation and adoption of appropriate solutions in order to minimize thermal bridges and reinforce the stability of the panel. For evaluation purposes some models are evaluated, with different connecting systems, configurations and different materials such as aluminium, stainless steel, galvanized steel and Glass Fibre Reinforced Polymer (GFRP) profiles. The quantification of thermal bridges, for evaluation of thermal performance, has been made using computing programs, HEAT2 and HEAT3. The evaluation of a system developed in this research work, i.e. incorporating profiles in thermal insulation, shows a good thermal resistance contributing significantly to the thermal insulation and energy conservation in building.

• Periodical: Key Engineering Materials (Volume 634)
• Pages: 62-71
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.634.62
• Online since: December 2014
• Authors: C. Cardoso, S. Jalali
• Keywords: Pre-Fabricated Panels, Thermal Bridges, Thermal Insulation

References

[1] National patent claim  PN106409: Prefabricated modular panel, modular system, , method of construction and use , invented by Viegas I., Pedrosa L. Jalali S., Cardoso C., 2012, (in Portuguese).

[2] European Technical Approvals Vetisol, Veture kit – Prefabricated unit for external wall insulation, ETA-09/0041, Centre Scientifique et Technique du Bâtiment (CSTB), Paris, (2009).

[3] European Technical Approvals PIZ, Veture kit – Prefabricated unit for external wall insulation, ETA-06/0135, Centre Scientifique et Technique du Bâtiment (CSTB), Paris, (2006).

[4] Information on http: /www. piz. it.

[5] Erhorn H., Citterio M., and other: Final Report of the IEE ASIEPI Work on Thermal Bridges, An effective Handling of Thermal Bridges in the EPBD Context, 31 March (2010).

[6] Valério, J.; Master's thesi, Impact assessment of thermal bridges on residential buildings performance ", Lisbon Technical University, September (2007).

[7] Tiago F., Corvacho M.: Hygrothermal analysis on the use of internal thermal insulation systems in portuguese residential buildings, Building Simulation, (2007).

[8] G. Evolaa, G. Marganib, L. Marlettac: Energy and cost evaluation of thermal bridge correction in Mediterranean climate, Energy and Buildings 43 (2011) 2385–2393.

DOI: 10.1016/j.enbuild.2011.05.028

[9] PORTUGAL. Laws, Decree-Law, RCCTE: Regulations on characteristics of the thermal behaviour of buildings. Decree-Law nº 80/2006, 4 Abril, Lisbon, 2006 (Portuguese thermal regulation for buildings).

[10] IPQ - European standard. Thermal bridges in building construction – Heat flows and surface temperatures – Detailed calculation, EN ISO 10211, (2007).

[11] HEAT2 Demo, 2D Heat transfer in two dimensions, Blocon, Sweden.

[12] HEAT3 Demo, 3D Heat transfer in three dimensions, Blocon, Sweden.

[13] ICT – Térmica: Coeficientes de Transmissão Térmica de Elementos da Envolvente dos Edifícios. ITE 50, Lisbon, (2006).

[14] Information on http: /www. amorimcorkcomposites. com.

[15] Information on http: /www. 5m. cz.

[16] Information on http: /www. cosmosaluminium. gr.

[17] IPQ - International standard. Building components and building elements - Thermal resistance and thermal transmittance - Calculation method, EN ISO 6946, (2007).

DOI: 10.3403/00942964

[18] Entranze Project. Overview of the EU-27 building policies and programmes- WP5 entranze, Information on http: /www. entranze. eu.

[19] European Organisation for Technical Approvals (EOTA) - Guideline for European Technical Approval of Vêtures Kit – Pre-fabricated for external wall insulation. Brussels: EOTA, November 2005. ETAG 17.
