Surface Micromachined Mirror Based on Pre-Stress Comb-Drive Actuator

Abstract:

A micromirror fabricated by surface micromachined process is developed. The developed micromirror contains four pre-stress comb-drive actuators, which support tip/tilt/piston degrees of freedom. Pre-stress comb-drive actuators have the advantage of large displacement and fast response. Prototype is fabricated by a commercially available MEMS surface micromachined process. Experimental results indicate that the device can realize designed function and have the potential in MOEMS applications.

• Periodical: Key Engineering Materials (Volumes 645-646)
• Pages: 1115-1119
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.645-646.1115
• Online since: May 2015
• Authors: Wei Min Wang, Sheng Mei Yan, Qiang Wang, Chuan Kai Qiu, Ze Xiang Chen, Bin Fan*
• Keywords: Electrostatically Actuated, Micromirror, Pre-Stress Comb-Drive Actuator (PCA), Surface Micromachined

References

[1] J. Chong, S. He and R. B. Mrad, Development of a Vector Display System Based on a Surface-Micromachined Micromirror, IEEE Trans Ind Electron. 59(12) (2012) 4863-4870.

DOI: 10.1109/tie.2011.2178210

[2] K. Jia, S. R. Samuelson and H. Xie, High-Fill-Factor Micromirror Array With Hidden Bimorph Actuators and Tip–Tilt-Piston Capability, J Microelectromech Syst. 20(3) (2011) 573-582.

DOI: 10.1109/jmems.2011.2127449

[3] T. G. Bifano and J. B. Stewart, High-speed wavefront control using MEMS micromirrors, Proc. SPIE. 5895 (2005) 1-9.

[4] H. Yu and H. Chen, Development of a novel micromirror based on surface micromaching technology, Sensors and Actuators A. 125 (2006) 458-462.

DOI: 10.1016/j.sna.2005.06.020

[5] D. Hah, S. T. -Y. Huang, J. -C. Tsai, H. Toshiyoshi and M. C. Wu, Low-Voltage, Large-Scan Angle MEMS Analog Micromirror Arrays With Hidden Vertical Comb-Drive Actuators, J Microelectromech Syst. 13(2) (2004) 279-289.

DOI: 10.1109/jmems.2004.825314

[6] F. R. Hu, J. Yao, C. K. Qiu and H. Ren, A MEMS micromirror driven by electrostatic force, J Electrostat. 68(3) (2010) 237-242.

DOI: 10.1016/j.elstat.2010.01.005

[7] P. R. Patterson, D. Hah, H. Nguyen, H. Toshiyoshi, R. -M. Chao and M. C. Wu, A SCANNING MICROMIRROR WITH ANGULAR COMB DRIVE ACTUATION, Proc. IEEE. (2002) 544-547.

DOI: 10.1109/memsys.2002.984329

[8] Q. Sun, K. He and E. Cretu, Optimization designed large-stroke MEMS micromirror for adaptive optics, CHINESE OPTICS LETTERS. 8(12) (2010) 1163-1166.

DOI: 10.3788/col20100812.1163

[9] J. C. Chiou and Y. J. Lin, A novel large displacement electrostatic actuator: pre-stress comb-drive actuator, J Micromech Microeng. 15 (2005) 1641-1648.

DOI: 10.1088/0960-1317/15/9/005

[10] J. -C. Chiou, C. -F. Kou and Y. -J. Lin, A Micromirror With Large Static Rotation and Vertical Actuation, IEEE J Sel Topics Quantum Electron. 13(2) (2007) 297-303.

DOI: 10.1109/jstqe.2007.892069

[11] Information on http: /www. memscap. com/en_mumps. html.

[12] D. Grigg, E. Felkel, J. Roth, X. C. D. Lega, L. Deck and P. D. Groot, Static and dynamic characterization of MEMS and MOEMS devices using optical interference microscopy, Proc. SPIE. 5455 (2004) 55-61.

DOI: 10.1117/12.546211
