Analysis on the Collision Couple between Drift Ice and Long-Span Prestressed Concrete T-Rigid Frame Bridge Pier

Abstract:

Long-span bridge across the river in cold areas, is often impacted by the drift ice in spring, thus having some severe effects on the stability and vibration of the bridge structure. With a long-span prestressed concrete T-rigid frame bridge as studied object, based on the display analysis function of the LS-DYNA software, this paper represents the simulating process of the contact and collision between the drift-ice and T-rigid frame bridge pier, and the influence of various factors was analyzed, such as model boundary condition, contact types of river ice and pier, algorithm and element connection transition area. Thus the reasonable calculation model of the collision force caused by drift-ice to pier was determined. The result has important theoretical and practical value to ensure the safety of the bridge in cold area, as well as to reduce the project cost.

• Periodical: Key Engineering Materials (Volume 648)
• Pages: 17-24
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.648.17
• Online since: June 2015
• Authors: Jian Min Zhang*, Zheng Guo Yuan, Ying Ping Wu
• Keywords: Collision, Contact, Couple Analysis, Drift-Ice, T-Rigid Frame Bridge

References

[1] Lin Cai. The Ice in Rivers of China. Yellow River Conservancy Press, 2008. (in Chinese).

[2] Zhiding Gao, Zhihong Zhang and Weihua Song. An overview of ice floods of Chinese rivers. Yellow river plan and design, 2007, 3: 1-18. (in Chinese).

[3] Peisheng Gao and Guohou Jin. Investigation and Analysis of Disasters of River Ice in Cold Regions of Northern China. Journal of China Institute of Water Resources Hydropower Research, 2003, 1(2): 159-164. (in Chinese).

[4] Lejiang Lin, Dongsheng Zhang and Zhenkai Wang. The Feature and Influence for bridge piers of the Spring Ice Floe in Nen River, Songhua River and Heilong River. Communications Science and Technology Heilongjiang, 1998, 2: 3-5. (in Chinese).

[5] Zhirui Cai, Botao Sun and Shirong Guo, Experimental and calculation method of the study of ice load. JOURNAL OF EARTHQUAKE ENGINEERING AND ENGINEERING VIBRATION, 1997, 17(4): 49-56. (in Chinese).

[6] Jacqueline A and Rickter-Menge. US research in ice mechanics: 1987-1990. Cold Regions Science and Technology, 1992, (20): 231-246.

DOI: 10.1016/0165-232x(92)90031-o

[7] Zhirui Cai, Jinji Li and Xiaoming Sun. The ice load of Jiamusi Highway Bridge. World Earthquake Engineering, 1994, (4): 49-52. (in Chinese).

[8] Tianlai Yu, Jinfeng Wang and Feng Du. Experimental research on Huma River ice disasters. Journal of natural disasters, 2007, 16(4): 43-48. (in Chinese).

[9] Tianlai Yu, Guozheng Yuan and Meilan Huang. Experimental research on mechanical properties of river ice. Journal of Liaoning Technical University, 2009, 28(6): 937-940. (in Chinese).

[10] Shengkui Su, Wenyou Sheng and Yun Liu. Effects of ice on hydraulic structures. Haihe Water Resources, 1992, (3): 42-48. (in Chinese).
