Numerical Investigation of a Stiffened Panel Subjected to Low Velocity Impacts

Abstract:

The investigation of fiber-reinforced composite laminates mechanical response under impact loads can be very difficult due to simultaneous failure phenomena. Indeed, as a consequence of low velocity impacts, intra-laminar damage as fiber and matrix cracking and inter-laminar damage, such as delamination, often take place concurrently, leading to significant reductions in terms of strength and stability for composite structure. In this paper a numerical study is proposed which, by means of non-linear explicit FEM analysis, aims to completely characterize the composite reinforced laminates damage under low velocity impacts. The numerical investigation allowed to obtain an exhaustive insight on the different phases of the impact event considering the damage formation and evolution. Five different impact locations with the same impact energy are taken into account to investigate the influence on the onset and growth of damage.

• Periodical: Key Engineering Materials (Volume 665)
• Pages: 277-280
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.665.277
• Online since: September 2015
• Authors: Aniello Riccio, S. Saputo, A. Sellitto, A. Raimondo, R. Ricchiuto
• Keywords: Damage Mechanics, Finite Element Analysis (FEA), Impact Behaviour, Laminate

References

[1] Abrate S. Modeling of impacts on composite structures. Compos Struct 2001; 51: 129–38.

[2] Riccio A, Raimondo A, Di Caprio F and Scaramuzzino F. Delaminations buckling and growth phenomena in stiffened composite panels under compression. Part II: a Numerical Study. Journal of Composite Materials 2013; DOI: 10. 1177/0021998313502742.

DOI: 10.1177/0021998313502742

[3] Elder DJ, Thomson RS, Nguyen MW, Scott ML. Review of delamination predictive methods for low speed impact of composite laminates. Compos Struct 2004; 66: 677–83.

DOI: 10.1016/j.compstruct.2004.06.004

[4] Riccio A, Raimondo A, Borrelli R, Mercurio U, Tescione D and Scaramuzzino F. Numerical Simulations of Inter-laminar damage evolution in a composite wing box. Applied Composite Materials 2013; DOI: 10. 1007/s10443-013-9347-2.

DOI: 10.1007/s10443-013-9347-2

[5] Hashin Z. Failure criteria for unidirectional fiber composites. J. Appl. Mech. 1980; 47: 329-334.

DOI: 10.1115/1.3153664

[6] Lapczyk I., Hurtado J.A. Progressive damage modeling in fiber-reinforced materials. Composites Part A: Applied Science and Manufacturing, Volume 38, Issue 11, November 2007, Pages 2333-2341.

DOI: 10.1016/j.compositesa.2007.01.017

[7] Bouvet C, Rivallant S, Barrau J.J. Low velocity impact modeling in composite laminates capturing permanent indentation. Compos Sci Technol 2012; 72(16); 1977–(1988).

DOI: 10.1016/j.compscitech.2012.08.019

[8] Olsson R, Donadon MV, Falzon BG. Delamination threshold load for dynamic impact on plates. Int J Solids Struct 2006; 43: 3124–41.

DOI: 10.1016/j.ijsolstr.2005.05.005

[9] Riccio A, Di Felice G, Saputo S and Scaramuzzino F. A Numerical Study on Low velocity impact induced damage in stiffened composite panels. Journal of Computational Simulation and Modeling 2013; 3(1): 044-047.

DOI: 10.1016/j.proeng.2014.11.148

[10] ABAQUS Analysis User's Manual 6. 11, (2011).
