Study on the Forming Accuracy and Density of Eucalyptus/PES Fabricated by Laser Sintering

Abstract:

. Based on orthogonal test, the forming accuracy and density of laser sintering eucalyptus/PES blend is studied in this paper. It mainly analysed the effect of the powder size and process parameters (such as laser power, layer thickness, preheating temperature, etc) on the forming precision and density of sintered eucalyptus/PES parts, also the correlation analysis of molding error caused by the powder’s physical properties and machine is performed. By measuring the parts’ dimensions, the results show that the laser power and powder size are two main factors influencing parts’ density, and variable density, layer thickness and preheating temperature jointly affect the dimensional accuracy. The optimized processing parameters are obtained. The powder size, laser power, scanning rate, layers thickness and preheating temperature are 300 mesh, 43W, 2000mm/s, 0.1mm, 60°C respectively.

You might also be interested in these eBooks

Advanced Engineering Materials and Processing Technologies

View Preview

Info:

Periodical:

Key Engineering Materials (Volume 667)

Pages:

200-205

DOI:

https://doi.org/10.4028/www.scientific.net/KEM.667.200

Citation:

Cite this paper

Online since:

October 2015

Authors:

Yan Ling Guo, Yue Qiang Yu, Kai Yi Jiang

Keywords:

Eucalyptus/PES Blend, Forming Ccuracy, Laser Sintering, Orthogonal Test

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] K.Y. Jiang, Y.L. Guo and W.L. Zeng: Advanced Materials Research. Vols. 113-114 (2010), pp.1722-1725, (2010).

Google Scholar

[2] Y.L. Guo, K.Y. Jiang and Z.X. Yu: Journal of Shanghai Jiaotong University. Vol. 45 (2011), No. 9, pp.1327-1330.

Google Scholar

[3] J.J. Beaman, J.W. Barlow and D.L. Bourell: Solid Freeform Fabrication: A New Direction in Manufacturing, (Kluwer Academic Publishers, USA 1997), pp.1-20.

DOI: 10.1007/978-1-4615-6327-3_4

Google Scholar

[4] R.S. Evans, D.L. Bourell and J.J. Beaman: RAPID PROTOTYPING JOURNAL. Vol. 11 (2005) No. 1, pp.37-40.

Google Scholar

[5] Y.G. Wang: Rapid Prototyping Technology (Centre China University of Technology Press, China 1999) pp.50-60.

Google Scholar

[6] Y.L. Guo, W.L. Zeng and K.Y. Jiang: Digest Journal of Nanomaterials and Biostructures. Vol. 6 (2011) No. 3, pp.1435-1444.

Google Scholar
