HLP Type Hydraulic Oil Analysis for Meso-Scale Hole Measurement

Abstract:

HLP type hydraulic oil has wide application in aerospace field. The existing measurement method of Laval nozzle throat diameter efficiency is low, and has the potential to cut parts surface. Therefore, a non-contact throat diameter measuring method based on the hydraulic oil is proposed. Then the flow field is simulated, and measurement parameters are calculated. The flow field analysis results show that this method is suitable for measuring Laval nozzle throat diameter.

• Periodical: Key Engineering Materials (Volume 667)
• Pages: 427-432
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.667.427
• Online since: October 2015
• Authors: Xiang Zhang, Yang Hong, Guang Lin Wang, Dong Xiang Shao, Li Sun
• Keywords: Flow Analysis, HLP Type Hydraulic Oil, Hydraulic Measurement, Laval Nozzle

References

[1] Wang L.P., Qiu A.C. and Kuai B. et al: High Power Laser & Particle Beams Vol. 2 (2005), p.102 (in Chinese).

[2] T. Masuzawa, B.J. Kim, C. Bergaud, et al: CIRP Annals - Manufacturing Technology Vol. 46 (1997), pp.437-440.

[3] T. Masuzawa, Y. Hamasaki and M. Fujino: CIRP Annals-Manufacturing Technology Vol. 42 (1993), pp.589-592.

DOI: 10.1016/s0007-8506(07)62516-5

[4] Wang P., Li C.P., Chen B.S.: Aeronautical Computing Technique Vol. 42 (2012), pp.60-62 (in Chinese).
