Analysis of Vibration Amplitude in High-Speed Cutting for Hardened Steel

Abstract:

The cutting vibration has a great influence on the processing quality of Hardened steel. The research conducted in this paper is about how the cutting parameters influence the cutting vibration amplitude when the hardened steel is cut. The experiments were performed on CNC lathe CAK4085 with PCBN tool, where the cutting speed, feed rate, cutting depth and corner radius had been orthogonally combined. The cutting materials were hardened steel Cr12MoV and GCr15 whose hardness is HRC50-52 and HRC62-64. The cutting vibration amplitude under different group parameters was collected by electric eddy current sensors. An analysis about the influence rule of cutting parameters on cutting vibration amplitude had been made. With the increase of cutting speed, vibration amplitude will increase first, and then decrease. With the appropriate increase of feed rate, vibration amplitude will be reduced. With the increase of cutting depth and corner radius, vibration amplitude will both increase. This research can provide reference for improving cutting quality.

• Periodical: Key Engineering Materials (Volume 667)
• Pages: 9-14
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.667.9
• Online since: October 2015
• Authors: Guang Jun Chen, Liang Wang, Bai Ting He, Ling Guo Kong, Xiao Qin Zhou
• Keywords: Corner Radius, Hardened Steel, Orthogonal Experiment, PCBN Tool, Vibration Amplitude

References

[1] L.Q. Ji, M.Y. Wang, et al: Machine Tool & Hydraulics. 2013, 41(23), pp.33-40.

[2] R. Teti, K. Jemielniak, et al: CIRP Annals-Manufacturing Technology, 2010, 59(2), pp.717-739.

[3] J. Chao. Huazhong University of Science and Technology, (2011).

[4] A.J. Tang, H.L. Ma: Tool Engineering. 2007, 41(8), pp.32-34.

[5] TAMIZHARSANT, SELVARAJT, HAP: Advanced Manufacturing Technology, 2006, 28, pp.671-678.

[6] Y.M. Zhang: North China University of Technology. (2006).

[7] W.B. Chu, D.J. Lin et al: Journal of Graphics. 2014, 35(1), pp.52-56.

[8] C.G. He, J. Xiong: JOURNAL OF SICHUAN UNIVERSITY. 2014, 46(3), pp.142-146.
