Technology Development of Large-Size Bodies Manufacturing from Thick Plate Materials Based on Combined Methods of Deformation

Abstract:

The main goal of the investigation is to determine key technological parameters, necessary for producing required curvature of sheets up to 4000 mm in width with the required mechanical properties. Investigation into dynamics of the process' main technological parameters allowed it to define its three characteristic stages: asymmetric rolling, asymmetric rolling in combination with initial unsettled plastic bending, and asymmetric rolling combined with settled plastic bending. It was found out that the intensity of the deformations changes unevenly, depending on the height of the deformation zone, on all three stages, with its highest value being in the lower part of the sheet, and with the lowest value being in its center. In the second stage, the intensity of the deformation abruptly increases, and a significant asymmetry on the sheet thickness occurs. In the third stage, the non-uniformity of the intensity deformations fields decreases. Similar results can be also observed for stress intensities. Casings on two converters were produced and installed in the oxygen-converter plant.

• Periodical: Key Engineering Materials (Volume 685)
• Pages: 375-379
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.685.375
• Online since: February 2016
• Authors: Alexander Pesin*, Ernst Drigun, D.O. Pustovoytov, Ilya Pesin
• Keywords: Asymmetric Rolling, Curvature, Large-Size Bodies of Rotations, Mathematical Modelling, Plastic Bending

References

[1] А.М. Pesin, V.М. Salganik, G.A. Kunitsin, The development and application of the processes of asymmetric rolling, Proceedings of the International Conference METEC (2003).

[2] A. Pesin, V. Salganik, E. Trahtengertz, M. Cherniahovsky, V. Rudakov, Mathematical modeling of the stress-strain state in asymmetric flattening of metal band, Journal of Materials Processing Technology. 125-126 (2002) 689-694.

DOI: 10.1016/s0924-0136(02)00353-9

[3] A. Pesin, Practical results of modeling asymmetric rolling, Steel in Translation 33 (2003) 46-49.

[4] A.M. Pesin, New solutions on basis of non-symmetric rolling model, Stal. (2003) 66-68.

[5] Zuo Fang-qing, Jiang Jian-hua, Shan Ai-dang, Fang Jian-min, Zhang Xing-yao, Shear deformation and grain refinement in pure Al by asymmetric rolling, Transactions of Nonferrous Metals Society of China. 18 (2008) 774-777.

DOI: 10.1016/s1003-6326(08)60133-8

[6] Y.H. Ji, J.J. Park, W.J. Kim, Finite element analysis of severe deformation in Mg-3Al-1Zn sheets throughout differential-speed rolling with a high speed ratio, Materials Science and Engineering A. 454-455 (2007) 570-574.

DOI: 10.1016/j.msea.2006.11.076

[7] M. Sverdlik, A. Pesin, D. Pustovoytov, A. Perekhozhikh, Advanced Materials Research. 742 (2013) 476-481.

DOI: 10.4028/www.scientific.net/amr.742.476

[8] Y.H. Ji, J.J. Park, Development of severe plastic deformation by various asymmetric rolling processes, Materials Science and Engineering A. 499 (2009) 14-17.

DOI: 10.1016/j.msea.2007.11.099

[9] G. Angella, Jahromi B. Esfandiar, M. Vedani, A comparison between equal channel angular pressing and asymmetric rolling of silver in the severe plastic deformation regime, Materials Science and Engineering A. 559 (2013) 742-750.

DOI: 10.1016/j.msea.2012.09.018

[10] Patent 38646 Rus, MPC7 В21В1/22. Device for asymmetrical rolling metal plate. А.М. Pesin, V.М. Salganik, E.М. Drigun, D.N. Chikishev. BIPM. 19 (2004).

[11] Patent 2254943 Rus, MPC7 В21В1/22. Device for asymmetrical rolling metal plate. А.М. Pesin; V.М. Salganik; E.М. Drigun; D.N. Chikishev. BIPM. 18 (2005).

[12] Patent 54831 Rus, MPC8 В21В1/22. Device for asymmetrical rolling metal plate. А.М. Pesin; V.М. Salganik; D.N. Chikishev. BIPM. 21 (2006).

[13] Patent 56592 Rus, MPC8 G01В 11/255. Device for measuring a radius of curvature of the cylindrical surface of large parts. А.М. Pesin. D.N. Chikishev. S.V. Blinov. BIPM. 25 (2006).

[14] Patent 87649 Rus, MPC7 В21В1/22. Device for asymmetrical rolling metal plate. А.М. Pesin, D.N. Chikishev, S.V. Blinov, D.О. Pustovoytov. BIPM. 29 (2009).
