Mobile Electric-Discharge Blasting Unit for Splitting off and Destruction of Rocks and Concrete

Abstract:

The article describes the pulse power system for electric-discharge blasting of rocks and concrete, the main equipment of which is a high current pulse generator with operating voltage up to 15 kV. The test of short-circuit experiment was produced, the main parameters of the discharge circuit L = 1.01 μH, R = 9 mΩ were calculated. Based on the results of the experiments the impedance Z = 42.5 mΩ of discharge circuit was defined. The pulse power system with mentioned parameters has maximum power condition deviation of about 8.6 %.

You might also be interested in these eBooks

High Technology: Research and Applications 2015

View Preview

Info:

Periodical:

Key Engineering Materials (Volume 685)

Pages:

705-709

DOI:

https://doi.org/10.4028/www.scientific.net/KEM.685.705

Citation:

Cite this paper

Online since:

February 2016

Authors:

Nikita Voitenko*, Artem S. Yudin

Keywords:

Electric-Discharge Blasting, Electro-Explosive Cartridge, High-Current Pulse Generator, Plasma Channel

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

* - Corresponding Author

References

[1] H. Hamelin, F. Kitzinger et. al. Hard rock fragmentation with pulsed power, Digest of 9th IEEE International Pulsed Power Conference, Albuquerque, New Mexico, USA, (1993) 11-14.

DOI: 10.1109/ppc.1993.512865

Google Scholar

[2] H. Inoue, I. V. Lisitsyn, H. Akiyama, and I. Nishizawa, Drilling of hard rocks by pulsed power, IEEE Electr. Insul. Mag., 3 (2000) 19-25.

DOI: 10.1109/57.845023

Google Scholar

[3] Y. SikJin, Y. Kim, J. Kim, Fabrication and testing of a 600-kJ pulsed power system, IEEE Transactions on plasma science, 10 (2013).

Google Scholar

[4] C. Silva, A. Stellin, W. Hennies , E. Costa, Electrohydraulic Rock Blasting: An Alternative for Mining in Urban Areas, International, Journal of Surface Mining, Reclamation and Environment, (2002) 261-269.

DOI: 10.1076/ijsm.16.4.261.8638

Google Scholar

[5] H. Bluhm, W. Frey, H. Giese et. al., Application of Pulsed HV Discharges to Material Fragmentation and Recycling, IEEE Transactions on Dielectric and Electrical Insulation, 5 (2000) 625-636.

DOI: 10.1109/94.879358

Google Scholar

[6] N. Kuznetsova, V. Lopatin, V. Burkin et. al., Theoretical and experimental investigation of electro discharge destruction of non-conducting materials, IEEE International Pulsed Power Conference: Digest of Technical Papers, (2011) 267-271.

DOI: 10.1109/ppc.2011.6191428

Google Scholar

[7] A. Yudin, N. Kuznetsova, V. Lopatin and N. Voitenko, Multi-borehole electro-blast method for concrete monolith splitting off, Journal of Physics: Conference Series, 552(2014) 1-4.

DOI: 10.1088/1742-6596/552/1/012028

Google Scholar

[8] V.A. Avrutsky et al. Testing and electro physical equipment's. Experimental Techniques –M.: MEI, (1983).

Google Scholar
