Numerical Analysis of Mechanical Phenomena in Coronary Stent Made of Titanium Alloy Ti-13Nb-13Zr

Abstract:

Using the finite element method, this study determined mechanical characteristics of slotted-tube stents. The numerical calculations were carried out using ADINA v.8.8 software. Three models with different number of segments were used. The analysis was carried out for the titanium-matrix alloys Ti-13Nb-13Zr. Assuming the actual conditions of stent implantation, the stent is expected to expand to the diameter of 3.0 mm i.e. until it reaches the internal diameter of a healthy coronary vessel. The effect of the stent geometry was analysed, with emphasis on examination of the effect of key mechanical phenomena such as expansion pressure and suitable level of stress and plastic strain in stents. Analysis of the degree of foreshortening and dogboning after stent expansion was also carried out. The following assumptions were adopted in order to determine mechanical properties of stents: implantation at low expansion pressure, limitation of foreshortening ≤ 2%, low increase in the implant diameter in the beginning and at the end of the stent (dogboning effect).

• Periodical: Key Engineering Materials (Volume 687)
• Pages: 191-198
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.687.191
• Online since: April 2016
• Authors: Aneta Idziak*
• Keywords: Dogboning, Expansion Pressure, Foreshortening, Titanium Matrix Alloy Ti-13Nb-13Zr

References

[1] K. Wang, The use of titanium for medical applications in the USA, Mat. Sci. Eng. A-Struct. 213 (1996) 134-137.

[2] J. Marciniak, Biomaterials, Silesian University of Technology, Gliwice 2002 (in Polish).

[3] A. Choubey, R. Balasubramaniam, B. Basu, Effect of replacement of V by Nb and Fe on the electrochemical and corrosion behaviour of Ti-6Al-7Nb in simulated physiological environment, J. Alloy. Compd. 381 (2004) 288-294.

DOI: 10.1016/j.jallcom.2004.03.096

[4] R. Ebner, J.M. Lackner, W. Waldhauser, R. Major, E. Czarnowska, R. Kustosz, P. Lacki, B. Major, Biocompatibile TiN-based novel nanocrystalline films, Bull. Pol. Acad. Sci-Te. 54/2 (2006) 167-173.

[5] M. Niinomi, Mechanical properties of biomedical titanium alloys, Mat. Sci. Eng. A-Struct. 243 (1998) 231-236.

[6] M. Niinomi, Recent research and development in titanium alloys for biomedical applications and healthcare goods, Sci. Technol. Adv. Mat. 4 (2003) 445-454.

[7] R. Caram, R.R. Chares, Influence of the Nb and Al content on the mechanical properties of Ti-Al-Nb alloys, Materials for Medical Engineering 2 (2000) 119-125.

DOI: 10.1002/3527606149.ch17

[8] R. Major, M. Sanak, A. Mzyk, L. Lipińska, M. Kot, P. Lacki, F. Bruckert, B. Major, Graphene based porous coating with anibacterial and antithrombogenous function - Materials and design, Arch. Civ. Mech. Eng. 14/4 (2014) 540-549.

DOI: 10.1016/j.acme.2014.04.012

[9] J.A. Davidson, P. Kovacs, USA Patent no. 4. 169. 597, (1992).

[10] Norma ASTM F1713-08 (2013), Standard Specification for Wrought Titanium-13Niobium-13Zirconium Alloy for Surgical Implant Applications (UNS R58130).

DOI: 10.1520/f1713-08r21e01

[11] B. Major, F. Bruckert, J.M. Lackner, R. Ebner, R. Kustosz P. Lacki, Coating on TiN and TI(C, N) basis for biomedical application to blood contact and TiN/CrN multilayered tribological systems produced by pulse laser deposition, Arch. Metall. Mater. 53/1 (2008).

[12] M. Kot, P. Lacki, Contact mechanics of coating-substrate systems. I. Methods of analysis and FEM modelling of nanoindentation tests, J. Balk. Tribol. Assoc. 18/4 (2012) 598-614.

[13] A. Ciekot, A. Idziak-Jabłońska, P. Lacki, Optimization of dogboning phenomenon of the coronary artery stent. Scientific Research of the Institute of Mathematics and Computer Science, Scientific Works of the Institute of Mathematics and Computer Science Czestochowa University of Technology 2/11 (2012).

DOI: 10.17512/jamcm.2012.2.03

[14] A. Idziak-Jabłońska, P. Lacki, Influence the number of segments and the thickness of the coronary stent on mechanical properties, [in: ] Monograph Mechanics in Medicine 2012, eds. 11 M. Korzyński J. Cwanek, Rzeszow University of Technology Publishing House, Rzeszow (2012).

[15] A. Idziak-Jabłońska, Stress and strain distribution in expanded coronary stents depending on applied material, Journal of Applied Mathematics and Computational Mechanics 14/2 (2015) 21-30.

DOI: 10.17512/jamcm.2015.2.03

[16] A. Idziak-Jabłońska, Modelling of mechanical phenomena in coronary stent based on numerical analysis, Mechanics 7 (2015) 303-310.

[17] K. Trembecka-Wojciga, R. Major, F. Bruckert, J.M. Lackner, P. Lacki, M. Sanak, B. Major, Computer engineering in designing and fabrication of tissue analogue-type coating dedicated for the cardiovascular regeneration, Arch. Civ. Mech. Eng. 15/3 (2015).

DOI: 10.1016/j.acme.2014.12.005

[18] A. Idziak-Jabłońska, Numerical analysis of mechanical phenomena in coronary stents, Dissertation, Czestochowa 2014 (in Polish).

[19] A. Idziak-Jabłońska, P. Lacki, R. Major, Effect of material and geometry on dogboning in coronary stent, Material Engineering 4/194 (2013) 269-272.
