Reliability Assessment of Bridge Column under Accidental Impact

Abstract:

It is shown that alternative procedures for probabilistic assessment of design impact forces given in EN 1991-1-7 leads to similar results. The impact forces are up to three times greater than the recommended indicative values given in the main text of EN 1991-1-7. Provided that no other safety measures are undertaken, the structures designed for recommended lower bound of impact forces may have insufficient reliability. Application of the upper limit of impact forces should be recommended for key bridges where the bridge columns are situated near road intersections or in the adverse configuration of the terrain.

• Periodical: Key Engineering Materials (Volume 691)
• Pages: 239-249
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.691.239
• Online since: May 2016
• Authors: Jana Marková*, Karel Jung
• Keywords: Accidental Action, Model of Impact Force, Probability of Failure, Reliability, Road Safety Barrier, Robustness

References

[1] EN 1990 Basis of structural design.

[2] EN 1991-1-7 Actions on structures - Part 1-7: General actions - Accidental actions.

[3] EN 1991-2 Actions on structures - Part 2 - Traffic loads on bridges.

[4] EN 1992-1-1 Design of concrete structures - Part 1-1: General rules and rules for buildings.

[5] EN 1992-2 Design of concrete structures - Part 2: Concrete bridges - Design and detailing rules.

[6] Background materials of CEN/TC250/SC 1 (1998), documents N153. 1, N167. 1, N183. 2, N183. 3, N221, 1995 to (1998).

[7] ISO DP 10252 Accidental actions due to human activities.

[8] TP 114 Road safety barriers on roads, Technical requirements, Ministry of Transport (2015).

[9] JCSS Probabilistic model code. JCSS, http: / www. jcss. byg. dtu. dk (2013).

[10] J. Markova, P. Marek, M. Kalinsky, Alternative procedures for the assessment of road safety barriers, Esrel (2014).

[11] J. Marková et al., Probabilistic Assessment of Traffic Loads on Bridges, In: Safety, Reliability and Risk Analysis: Beyond the Horizon. pp.2613-2618 (2014).

DOI: 10.1201/b15938-394

[12] K. Jung, J. Markova, Analysis of reliability and retaining level of safety barriers, Safety and reliability methodology and applications, pp.2261-2267, Esrel (2014).

DOI: 10.1201/b17399-310

[13] Z. Winter, J. Vala, A contribution to assessment of transportation structures vulnerability, Applied Mechanics and Materials, Vol. 656, Trans Tech Publications Ltd., Switzerland, pp.588-595 (2014).

DOI: 10.4028/www.scientific.net/amm.656.588

[14] Z. Winter, J. Vala, Effects of a vehicle crash into a column, In: 18th International conference Transport Means, Kaunas University of technology, Lithuania, pp.157-160 (2014).

[15] M. Holicky et al., Robustness of Structures, CTU in Prague, p.204 (2011).
