Experimental Analysis of Elastic-Plastic Free Vibrations of Beam Models Caused by Impact

Abstract:

An experimental analysis was performed to model transverse impact of free-free and free supported square duralumin beams loaded at different locations along their length. The applied impact load was obtained from tests carried out on a single Hopkinson pressure bar equipped with a high speed camera. The experimental set-up consisted of an Hopkinson measuring bar that is brought in contact with the beam. In this one-point impact experiment, a cylindrical striker, fired by the air gun, impacts the Hopkinson bar and generates stress waves that travel along the bar and impinge upon the aluminum beam. The stress waves are recorded by strain gages mounted on the Hopkinson measuring bar. These are used to calculate the applied load on the beam. Dynamical displacements of the impact zone of tested beam were recorded by the high speed camera. The dynamic experiments show that the plastic deformation, adjacent to the impact location, is due to combined dominant bending and stretching modes. Most of the plastic deformation is confined to the impact zone of tested beams. The plastic strain magnitude and distribution near the impact zone is similar for all tested impact locations, but higher for the more symmetrical impacts. The conversion of impact energy into kinetic, elastic strain energy and plastic dissipation work is characterized for various impact locations along the specimen of beam.

• Periodical: Key Engineering Materials (Volume 715)
• Pages: 254-260
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.715.254
• Online since: September 2016
• Authors: Grzegorz Jemielita, Zofia Kozyra, Leopold Kruszka*
• Keywords: Elastic-Plastic Material, Free Vibrations, Hopkinson Bar, Transverse Impact Large Strain

References

[1] N. Jones, Structural Impact, Cambridge University Press, (1997).

[2] E.H. Lee, P.S. Symonds, Large deformations of beams under transverse impast, Journal of Applied Mechanics 19 (1952) 308-314.

DOI: 10.1115/1.4010503

[3] N. Jones, T. Wierzbicki, Dynamic plastic failure of a free-free beam, International Journal of Impact Engineering, 6 (1987) 225-240.

DOI: 10.1016/0734-743x(87)90022-4

[4] J.L. Yang, T.X. Yu, S.R. Reid, Dynamic behaviour of a rigid, perfectly plastic free-free beam subjected to step-loading at any cross-section along its span, International Journal of Impact Engineering, 21 (1998) 165-175.

DOI: 10.1016/s0734-743x(97)00048-1

[5] T.X. Yu, J.L. Yang, S.R. Reid, C.D. Austin, Dynamic behaviour of elastic-plastic free-free beams subjected to impulsive loading, International Journal of Solids Structures, 33 (1996) 2659-2680.

DOI: 10.1016/0020-7683(95)00169-7

[6] J.L. Yang, F. Xi, Experimental and theoretical study of free-free beam subjected to impact at any cross-section along its span, International Journal of Impact Engineering, 28 (2003) 761-781.

DOI: 10.1016/s0734-743x(02)00123-9

[7] A. Dorogoy, D. Rittel, Transverse impact of square aluminum beams: an experimental - numerical investigation, International Journal of Impact Engineering, 35 (2008) 569-577.

DOI: 10.1016/j.ijimpeng.2007.05.004

[8] PN-EN 755-2: 2001 Polish – European Standard, Aluminum and aluminum alloys. Bars, tubes and extruded sections. Mechanical properties (in Polish).

[9] L. Kruszka, W.K. Nowacki, New applications of Hopkinson's pressure bar technique for determining dynamic behaviour of materials, Journal of Theoretical and Applied Mechanics, 34 (1996) 259–280.
