Visualization of Contact-Pressure Distribution between Material and Backing Plate in Friction Stir Processing

Abstract:

In this study, the authors evaluated pressure distribution on a backing plate in friction-stir processing (FSP) utilizing an embedded pressure pin connected to a load sensor. They conducted FSP on aluminum alloy plates repeatedly offsetting the path-lines from the center of the pin and recorded change of forming pressure with tool position, which was compiled from the bearing load of the pin. The authors mapped the results to visualize the two-dimensional contact pressure distribution on a backing plate during FSP. They then compared the height distribution of the wall fabricated by friction-stir forming (FSF) utilizing a die having a groove with the observed distribution of pressure. Consequently, maximum pressure was observed beneath the rim of the tool probe at the retreating side (RS), and the highest points of the wall were observed at the RS.

• Periodical: Key Engineering Materials (Volume 765)
• Pages: 199-203
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.765.199
• Online since: March 2018
• Authors: Takahiro Ohashi*, Xin Tong, Zi Jie Zhao, Hamed Mofidi Tabatabaei, Tadashi Nishihara
• Keywords: Friction Stir Processing (FSP), In-Process Sensing, Pressure Distribution, Visualization

References

[1] M.W. Thomas, J.Nicholas, J.C. Needham, M.G. Murch, P.Templesmith, C.J. Dawes, US Patent, 5,460,317. (2001).

[2] T.Nishihara, Japanese Patent No. 4,646,421.(2002).

[3] T.Ohashi, T.Nishihara, Cylindrical Extrusions on A5083 Aluminum Alloy Plate Fabricated by Friction Stir Forming, AIP Conf. Proc. (Proc. ESAFORM2017), Vol.1896-080002 (2017), pp.(080002-1)-(080002-6).

DOI: 10.1063/1.5008082

[4] M.Otsu, Y.Katayama, T.Muranaka, Effect of Difference of Tool Rotation Direction on Forming Limit in Friction Stir Incremental Forming, Key Engineering Materials, Vol.622/623-1 (2014) 390-397.

DOI: 10.4028/www.scientific.net/kem.622-623.390

[5] E.Yukutake, Y.Motohashi, M.Kouta, S.Negishi, New Method of Boss Forming on Magnesium Alloy Sheet by Friction Stir Technology, Proc. 69th Annual World Magnesium Conference, (2012), pp.85-90.

[6] K.Colligan, Material Flow Behavior during Friction Stir Welding of Aluminum, Welding Journal, Vol. 78(1999), pp.229-237.

[7] Y.Matsuura, M.Motomura, T.Toshio, Studies on pressure distribution in compression of block between parallel plates, J.Japan Inst.Light Metar., Vol.22 No.2(1972), pp.101-111.

DOI: 10.2464/jilm.22.101

[8] T.Ohashi, H.Mofidi Tabatabaei, T.Nishihara, Vertical Wall on an Aluminum Alloy Plate Fabricated by Friction Stir Forming, Key Engineering Materials, Vol.748(2017), pp.202-206.

DOI: 10.4028/www.scientific.net/kem.748.202

[9] T.Ohashi, H.Mofidi Tabatabaei, T.Nishihara, Evaluation of Material Deformability and Pressure Distribution on a Die Surface under a Tool in Spot FSF, Defect and Diffusion Forum, Vol.382(2018),pp.132-137.

DOI: 10.4028/www.scientific.net/ddf.382.132
