Development of Pressure Sensitive Glove Prototype

Abstract:

Manual therapy is used to treat patients with neck pain, and mobilization techniques are practiced clinically by physiotherapists. To evaluate the effectiveness of therapy it is necessary to measure the applied manual therapy forces. We present the sensitive glove concept designed to measure the forces applied during therapy. The sensitive glove is equipped with multiple textile-based sensors connected by sewing technology, in which changes in electrical resistance were observed due to the applied force. The number and position of sensors were defined basing on the experience of manual therapists and practicable techniques. Glove fabrication technologies were tested practically – sensors were glued and sewn on the base material and simple conductive threads were sewn by hand and with a sewing machine. Technological solutions were evaluated both in terms of visual and technical aspects. The final version of the sensitive glove was assessed by an expert and recommendations were given for improving further prototypes.

• Periodical: Key Engineering Materials (Volume 800)
• Pages: 326-330
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.800.326
• Online since: April 2019
• Authors: Natalija Baribina, Alexander Oks, Ilze Baltiņa, Aleksei Katashev, Guna Semjonova, Elina Bergmane
• Keywords: Data Glove, Electrically Conductive Yarn, Pressure Sensor, Sensitive Glove

References

[1] S.J. Snodgrass, D.A. Rivett, V.J. Robertson, E. Stojanovski, A comparison of cervical spine mobilization forces applied by experienced and novice physiotherapists, Journal of Orthopaedic and Sports Physical Therapy. 40(7) (2010) 392-401.

DOI: 10.2519/jospt.2010.3274

[2] S.J. Snodgrass, D.A. Rivett, V.J. Robertson, Calibration of an instrumented treatment table for measuring manual therapy forces applied to the cervical spine, Manual Therapy. 13 (2) (2008) 171-179.

DOI: 10.1016/j.math.2007.04.002

[3] S.F. Ahmed, S.M.B. Ali and S.S.M. Qureshi, Electronic speaking glove for speechless patients, a tongue to a dumb, 2010 IEEE Conference on Sustainable Utilization and Development in Engineering and Technology, Petaling Jaya, 2010, 56-60.

DOI: 10.1109/student.2010.5687009

[4] R. Saxena, T. Mahajan, P. Sharma and M. Sood, Braille hand glove - A real time translation and communication device, 3rd International Conference on Computing for Sustainable Global Development (INDIACom), New Delhi, 2016, 1714-1718.

[5] J. Connolly, J. Condell, B. O'Flynn, J.T. Sanchez and P. Gardiner, IMU sensor-based electronic goniometric glove for clinical finger movement Analysis, IEEE Sensors Journal. 18.3 (2018) 1273-1281.

DOI: 10.1109/jsen.2017.2776262

[6] L. Plant, B. Noriega, A. Sonti, N. Constant and K. Mankodiya, Smart E-textile gloves for quantified measurements in movement disorders, 2016 IEEE MIT Undergraduate Research Technology Conference (URTC),Cambridge, MA, 2016, 1-4.

DOI: 10.1109/urtc.2016.8284077

[7] A.M.M. Ali, Z.M.D. Yusof, A.K. Kushairy, F.H. Zaharah and A. Ismail, Development of smart glove system for therapy treatment, International Conference on BioSignal Analysis, Processing and Systems (ICBAPS), 2015, 67-71.

DOI: 10.1109/icbaps.2015.7292220

[8] Information on http://www.cyberglovesystems.com.

[9] Information on https://mimugloves.com.

[10] Information on https://www.kobakant.at.

[11] A. Escoto, A.L. Trejos, D.M. Walton and J. Sadi, A sensorized glove for therapist skill performance assessment during neck manipulation, IEEE 30th Canadian Conference on Electrical and Computer Engineering (CCECE), Windsor, 2017, 1-4.

DOI: 10.1109/ccece.2017.7946587

[12] L. Dipietro, A.M. Sabatini and P. Dario, A survey of glove-based systems and their applications, IEEE Transactions on Systems, Man, and Cybernetics, Part C (Applications and Reviews). 38-4 (2008) 461-482.

DOI: 10.1109/tsmcc.2008.923862
