Combined In Situ X-Ray Computed Tomography and Acoustic Emission Analysis for Composite Characterization - A Feasibility Study

Abstract:

Fiber reinforced plastics show a wide range of different damage mechanisms such as matrix cracking, fiber breakage and interface failure. These can be observed in damaged specimens by means of volumetric images acquired by computed tomography (CT). As each failure mechanism causes a characteristic acoustic emission (AE) signal, AE analysis is a promising tool to identify damage mechanisms and offers the advantage that a real-time observation of the damage evolution during the testing period is possible. For a correlation of damage mechanisms and AE events, AE analysis was combined with in- situ CT measurements. This combined approach was validated by means of a 3-point-bending test on a discontinuous glass fiber reinforced sheet molding compound (GF-SMC) in which AE signals were acquired during loading using two high frequency piezoelectric sensors. At times of increasing AE activity, the test was interrupted in order to carry out a CT-scan of the specimen under load. AE events could subsequently be linked with the damage mechanisms observed in the CT-scans at different stages of damage to identify signal features that are characteristic for a certain mechanism. The sources of the signals could be localized and were in line with the actual location of damage.

• Periodical: Key Engineering Materials (Volume 809)
• Pages: 604-609
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.809.604
• Online since: June 2019
• Authors: Miriam Bartkowiak*, Ludwig Schoettl, Peter Elsner, Kay André Weidenmann
• Keywords: Acoustic Emission, Damage Mechanisms, Micro Computed Tomography (μCT) Analysis, Sheet Molding Compound

References

[1] F. Meraghni, F. Desrumaux, M. L. Benzeggagh, Implementation of a constitutive micromechanical model for damage analysis in glass mat reinforced composite structures Compos. Sci. Technol. 62.16 (2002) 2087-2097.

DOI: 10.1016/s0266-3538(02)00110-0

[2] S.C. Garcea, Y. Wang, P.J. Withers: X-ray computed tomography of polymer composites, Compos. Sci. Technol. 156 (2018) 305-319.

DOI: 10.1016/j.compscitech.2017.10.023

[3] A. Amirkhanov, A. Amirkhanov, D. Salaberger, M.E. Gröller, C. Heinzl, Visual analysis of defects in glass fiber reinforced polymers for 4DCT interrupted in situ tests, Comput. Graph. Forum. 35.3 (2016) 201-210.

DOI: 10.1111/cgf.12896

[4] M.G. Sause, In situ monitoring of fiber-reinforced composites: theory, basic concepts, methods, and applications, Springer, (2016).

[5] S. Barré, M.L. Benzeggagh, On the use of acoustic emission to investigate damage mechanisms in glass-fiber-reinforced polypropylene, Comp. Sci. Technol., 52 (1994), 369-376.

DOI: 10.1016/0266-3538(94)90171-6

[6] C. R. Ramirez-Jimenez, N. Papadakis, N. Reynolds, T. H. Gan, P. Purnell, M. Pharaoh, Identification of failure modes in glass/polypropylene composites by means of the primary frequency content of the acoustic emission event, Comp. Sci. Technol., 64.12 (2004), 1819-1827.

DOI: 10.1016/j.compscitech.2004.01.008

[7] M. G. Sause, A. Gribov, A.R. Unwin, S. Horn, Pattern recognition approach to identify natural clusters of acoustic emission signals, Pattern Recognition Letters, 33.1 (2012), 17-23.

DOI: 10.1016/j.patrec.2011.09.018

[8] P. Potstada, S. Rosini, M. Mavrogordato, I. Sinclair, S. M. Spearing, M. G. Sause, Cross-Validation of Single Filament Failure by Acoustic Emission and High-Resolution Synchrotron Computed Tomography, ECCM18, Athens, (2018).

[9] A. Trauth, P. Pinter, K.A. Weidenmann, Investigation of Quasi-Static and Dynamic Material Properties of a Structural Sheet Molding Compound Combined with Acoustic Emission Damage Analysis, J. Compos. Sci. 1.2 (2017) 18.

DOI: 10.3390/jcs1020018

[10] Vallen Systeme GmbH, AE–Sensor Data Sheet VS600-Z2: http://www.vallen.de/.

[11] DIN EN1330-9, Zerstörungsfreie Prüfung – Terminologie, 9, 2009-09.
