Multi-Layer Cold Spray Coating: Strain Distribution

Abstract:

In this paper, we report the effect of multi-layer cold spray deposition on the residual stress formation in the coating and substrate. A method is proposed to separately measure the thermal and mechanical residual stresses induced in cold spray coating. Fiber Bragg Grating (FBG) sensors were employed for in situ monitoring of the strain evolution during the cold spray of multi-layer coating Al7075-Zn on AZ31B Magnesium substrates. Utilizing the capability of the FBG sensors in recording both thermal and mechanical strain gradients, first the effect of temperature on the substrate was investigated when the sample was only treated under carrier gas temperature. Then, the sensors were employed to evaluate the mechanical strain behavior of substrate during the coating process and cooling. Therefore, the effect of thermal mismatch on inducing mechanical strains was observable during the process. Finally, the interaction between the peening process of cold spray and thermal mismatch after cooling was studied. It is shown that the thermal expansion coefficient (CTE) plays a critical role in residual stress development in the substrate and consequently affects the mechanical properties of the coated sample. Hence, careful selection of layers in multilayer deposition can provide desired residual stress in the coating and substrate.

• Periodical: Key Engineering Materials (Volume 813)
• Pages: 411-416
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.813.411
• Online since: July 2019
• Authors: Bahareh Marzbanrad*, Ehsan Toyserkani, Hamid Jahed
• Keywords: Cold Gas Dynamic Spraying, Fiber Bragg Grating Sensors, Magnesium Alloys, Pure Zinc

References

[1] H. Assadi, H. Kreye, F. Gärtner, T. Klassen, Cold spraying – A materials perspective, Acta Materialia. 116 (2016) 382-407.

DOI: 10.1016/j.actamat.2016.06.034

[2] M. Hassani-Gangaraj, D. Veysset, V.K. Champagne, K.A. Nelson, C.A. Schuh, Adiabatic shear instability is not necessary for adhesion in cold spray, Acta Materialia. 158 (2018) 430-439.

DOI: 10.1016/j.actamat.2018.07.065

[3] B. Marzbanrad, F. Ahmed, H. Jahed, E. Toyserkani, Application of FBG optical sensors to in-situ monitoring the thermomechanical behaviour of cold spray coated samples, CSME International Congress 2018, Toronto, On, Canada.

DOI: 10.25071/10315/35388

[4] R. Kashyap, Fiber Bragg Gratings, Second ed., Elsevier, United States of America, (2010).

[5] B. Marzbanrad, H. Jahed, E. Toyserkani, On the sensitivity and repeatability of fiber Bragg grating sensors used in strain and material degradation measurement of Magnesium alloys under cyclic loads, Int. J. Adv. Manufact. Technol. 86(9-12) (2016) 3453-3461.

DOI: 10.1007/s00170-016-8485-8

[6] B. Marzbanrad, H. Jahed, E. Toyserkani, On the evolution of substrate's residual stress during cold spray process: A parametric study, Materials & Design. 138 (2018) 90-102.

DOI: 10.1016/j.matdes.2017.10.062

[7] L. Qian, A. Roostaei, U. Dighrasker, G. Glinka, H. Jahed, Notch plasticity and fatigue modelling of AZ31B-H24 magnesium alloy sheet, SAE Technical Paper 2019-01-0530 (2019).

DOI: 10.4271/2019-01-0530

[8] S.B. Dayani, S.K. Shaha, R. Ghelichi, J.F. Wang, H. Jahed, The impact of AA7075 cold spray coating on the fatigue life of AZ31B cast alloy, Surface and Coatings Technology. 337(2018), 150-158.

DOI: 10.1016/j.surfcoat.2018.01.008

[9] M. Kreuzer, Strain measurement with fiber Bragg grating sensors, in: HBM (Ed.) Darmstadt, Germany.

[10] F. Wang, M. Zhao, Simulation of particle deposition behavior in cold-sprayed Mg anticorrosion coating, Materials and Manufacturing Processes. 31(11) (2014) 1483-1489.

DOI: 10.1080/10426914.2014.952042
