Visualization and Quantification of Stresses at the Ends of Short Fibers Embedded in Epoxy Resin

Abstract:

The photoelastic effect was used to visualize and quantify stresses at the end of fibers embedded in birefringent epoxy resin. A method was proposed allowing not to only quantify the differences in main principal stress for a single loading state, but to allow monitoring the evolution of local stress throughout the micro-mechanical experiment. It was found that the ends of fibers foster the formation of shear stresses which influence the principal stress distribution. Typically, star-shaped principal stress distributions were found at the ends of fibers. Finite Element simulations of the tests were in good agreement with the experimental evidence.

• Periodical: Key Engineering Materials (Volume 858)
• Pages: 66-71
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.858.66
• Online since: August 2020
• Authors: Michael May*, Holger Mohrmann, Hartwig Nahme
• Keywords: Carbon Fiber, Optical Microscopy, Photoelasticity, Polymer-Matrix Composites, Stress Concentration
