Li-Doped SnO₂ Electron Transport Layer for High-Performance Perovskite Solar Cell Fabricated Using Magnetic Field-Assisted Electrodeposition

Abstract:

One of the key challenges for the development of perovskite solar cells lies in the approach toward large-scale fabrication of the active materials that allows for good photovoltaic performance, as well as facile handling. The electrodeposition technique can potentially address such requirements. However, the technique has yet to be investigated in detail and still suffers from low efficiency of the device. In this study, we sought to significantly upgrade the electrodeposition approach by coupling the technique with an external magnetic field in the preparation of high-quality PbI₂ precursor layer and using Li-doped SnO₂ electron transport layer. Our results showed that the magnetic field-assisted electrodeposition yielded good crystallinity of PbI₂ and perovskite. Introducing the Li-doped mesoporous SnO₂ into the device structure resulted in a higher current density of 18.50–18.80 mA cm^-2, which can be attributed to, based on the linear sweep voltammetry, reduced resistance of the electron transport layer from 32.27 to 22.11 Ω cm^-2. Moreover, the carbon-based device prepared using this simple procedure also yielded 5.20% in photoconversion efficiency for 1-cm² active area and 0.45% for 25-cm² active area, all without any significant hysteresis.

• Periodical: Key Engineering Materials (Volume 927)
• Pages: 161-166
• DOI: https://doi.org/10.4028/p-1yx4e1
• Online since: July 2022
• Authors: Demas Aji, Pasit Pakawatpanurut*
• Keywords: Ambient Air Processing, Carbon-Based Solar Cell, Electrodeposition, Large Active Area, Li Doping, Magnetic Field, Perovskite, Tin (IV) Oxide

References

[1] A. Kojima, K. Teshima, Y. Shirai, T. Miyasaka, Organometal Halide Perovskites as Visible-Light Sensitizers for Photovoltaic Cells, J. Am. Chem. Soc. 131(17) (2009) 6050-6051.

DOI: 10.1021/ja809598r

[2] J. Jeong, M. Kim, J. Seo, H. Lu, P. Ahlawat, A. Mishra, Y. Yang, M.A. Hope, F.T. Eickemeyer, M. Kim, Y.J. Yoon, I.W. Choi, B.P. Darwich, S.J. Choi, Y. Jo, J.H. Lee, B. Walker, S.M. Zakeeruddin, L. Emsley, U. Rothlisberger, A. Hagfeldt, D.S. Kim, M. Grätzel, J.Y. Kim, Pseudo-halide anion engineering for α-FAPbI3 perovskite solar cells, Nature 592(7854) (2021) 381-385.

DOI: 10.1038/s41586-021-03406-5

[3] J.C. Hill, J.A. Koza, J.A. Switzer, Electrodeposition of Epitaxial Lead Iodide and Conversion to Textured Methylammonium Lead Iodide Perovskite, ACS Appl. Mater. Interfaces 7(47) (2015) 26012-26016.

DOI: 10.1021/acsami.5b07222

[4] D. Aji, P. Pakawatpanurut, Ambient processing of methylammonium lead iodide perovskite solar cells via magnetic field-assisted electrodeposition of the precursor film, Sol. Energy 233 (2022) 204-212.

DOI: 10.1016/j.solener.2022.01.044

[5] W. Li, J. Yang, Q. Jiang, R. Li, L. Zhao, Electrochemical deposition of PbI2 for perovskite solar cells, Sol. Energy 159 (2018) 300-305.

DOI: 10.1016/j.solener.2017.10.077

[6] I. Kosta, H. Grande, R. Tena-Zaera, Dimethylformamide-free processing of halide perovskite solar cells from electrodeposited PbI2 precursor films, Electrochim. Acta 246 (2017) 1193-1199.

DOI: 10.1016/j.electacta.2017.06.104

[7] H. Wang, J. Lei, F. Gao, Z. Yang, D. Yang, J. Jiang, J. Li, X. Hu, X. Ren, B. Liu, J. Liu, H. Lei, Z. Liu, S. Liu, Magnetic Field-Assisted Perovskite Film Preparation for Enhanced Performance of Solar Cells, ACS Appl. Mater. Interfaces 9(26) (2017) 21756-21762.

DOI: 10.1021/acsami.7b03081

[8] M. Park, J.-Y. Kim, H.J. Son, C.-H. Lee, S.S. Jang, M.J. Ko, Low-temperature solution-processed Li-doped SnO2 as an effective electron transporting layer for high-performance flexible and wearable perovskite solar cells, Nano Energy 26 (2016) 208-215.

DOI: 10.1016/j.nanoen.2016.04.060

[9] L. Xiong, M. Qin, G. Yang, Y. Guo, H. Lei, Q. Liu, W. Ke, H. Tao, P. Qin, S. Li, H. Yu, G. Fang, Performance enhancement of high temperature SnO2-based planar perovskite solar cells: electrical characterization and understanding of the mechanism, J. Mater. Chem. A 4(21) (2016) 8374-8383.

DOI: 10.1039/c6ta01839d

[10] N. Liu, M. Chen, H. Yang, M. Ran, C. Zhang, X. Luo, H. Lu, Y. Yang, TiO2/Mg-SnO2 nanoparticle composite compact layer for enhancing the performance of perovskite solar cells, Opt. Mater. Express 10(1) (2019).

DOI: 10.1364/ome.380354

[11] Z. Liu, T. Shi, Z. Tang, B. Sun, G. Liao, Using a low-temperature carbon electrode for preparing hole-conductor-free perovskite heterojunction solar cells under high relative humidity, Nanoscale 8(13) (2016) 7017-7023.

DOI: 10.1039/c5nr07091k

[12] S. He, L. Qiu, D.-Y. Son, Z. Liu, E.J. Juarez-Perez, L.K. Ono, C. Stecker, Y. Qi, Carbon-Based Electrode Engineering Boosts the Efficiency of All Low-Temperature-Processed Perovskite Solar Cells, ACS Energy Lett. 4(9) (2019) 2032-2039.

DOI: 10.1021/acsenergylett.9b01294

[13] Y. Qiang, Y. Xie, Y. Qi, P. Wei, H. Shi, C. Geng, H. Liu, Enhanced performance of carbon-based perovskite solar cells with a Li+-doped SnO2 electron transport layer and Al2O3 scaffold layer, Sol. Energy 201 (2020) 523-529.

DOI: 10.1016/j.solener.2020.03.046
